Fireproof Tasteless Acoustic Wood Ceiling , Odorless Sound Absorbing Acoustic Panel
Acoustic Wooden Slat Wall Panels Fire Resistant Sound Absorb Material
Product Parameters
| Product Name | Fire Resistant Sound Absorb Material |
| Pattern | MDF 27mm, Edge to edge 13mm / customized |
| Standard Size | 2400*600*21mm / customized |
| MDF Thickness | 12mm/15mm/18mm |
| Polyester Thickness | 9mm/12mm |
| Finish | Melamine / Veneer / Painting |
| Material | Basic: Engineered Veneer+MDF +Felt made of recycled plastic Bottleshe Surface: Fireproof finished / Wood Finished / Melamine Finished |
| Bottom | PET polyester panel |
| Test | Eco protection, Sound absorption, Fire-retardant |
| Function | Sound absorption / Interior decoration |
| Noise Reduction Coefficient |
0.85~0.94,SGS Test for polyester panel |
Product Features:
1. With excellent sound absorbing performance. The NRC can be 0.85 to 0.94.
2. Easy to cut by knife and easy to install by glue or nail.
3. Good physical stability, will not inflate or shrink due to the change of temperature.
4. Soft and natural texture. It will not get broken under huge impact of high elasticity.
5. Easy dust removal and easy maintenance by vacuum cleaner or feather dust.
PRODUCT USE SCENARIO
Ensure clear language and reduce echoes in gymnasiums, badminton halls, tennis courts, etc.
Reduce echo to increase speech and music clarity in theaters, cinemas, concert halls, churches, etc.
Inprove indoor environmental quality and comfort in museums, hospitals, rail station, airport, etc.
Improve speech intelligibility in classroom, function room.
Acoustic treatment to meet the design of offices, hotels, banquet halls, restaurants, etc.
Product Installation
Panels can be mounted with very few tools - the panel is mounted on 5 horizontal bars with black screws. You will find E0 hot glue,spray glue or gun nail to install on the wall. Here,the underlying walls are painted white on top and black on bottom. Extra attention was paid to detail and the edges of the doors and Windows were decorated with elegant oak lines. Since the panels are mounted on the joists/wooden beams, they can be removed again. This makes them suitable for rental homes that would otherwise not be able to be painted, wallpapered or similar variations.
1. Install 45mm (thickness) battens directly to your wall/ceiling with a distance of 600mm.
2. Install the acoustic panels directly on the battens with screws (min. 3.5mm × 35mm). You can easily fit the screws between the lamellas into the underlying acoustic felt. Every panel is installed with 15 screws.
3. Cutting the panels is easily done with a fine jagged saw. The underlying acoustic felt is easily cut with a good knife.
4. For an expanded acoustic solution, you can place 45mm insulation between the studs.
