0.1um Flat Sheet MBR 620 X 2250 X 2200mm Sludge Treatment 0.1um Membrane Bioreactor Process
Flat MBR for Sludge Treatment with PVDF material 0.1um pore size
Flat sheet membrane and module outstanding advantages:
(1) Not easy to pollution, low frequency for the membrane cleaning, no need to backwash flat sheet membrane equipment when operation, easy operation for the cleaning;
(2) Immersion setting, stable placed in the reaction tank;
(3) Output water in low pressure (sucking or gravity);
(4) Even aeration effect, small aeration flow rate;
(5) Stable operation in long time working under the condition of TSS 15000 mg/L;
(6) Low energy consumption operation;
(7) Membrane sheet can be single replaced;
(8) No risk of rupture of membrane sheet, and guarantee excellent water quality.
Product Description
Membrane Bioreactor MBR sheet (pcs.)
| Items | Standard type | Long type |
| Model | KH-MBRP-80-PVDF | KH-MBRP-150-PVDF |
| Size (LxWxT) | 1000×490×7 | 1850×510×7 |
| Membrane effective area (m²) | 0.8 | 1.5 |
| Weight (kg) | 3 | 4.5 |
| Permeate flux [L/ (pc.d)] | 320-480 | 600-900 |
| Membrane material | PVDF | PVDF |
| Membrane pore size (μm) | 0.1 | 0.1 |
| Plate material | ABS | ABS |
| Air flow rate [L/(min.pc)] | ≥ 10 | ≥ 12 |
| pH | 2 ~ 13 | 2 ~ 13 |
| Output turbidity (NTU) | < 1.0 | < 1.0 |
| Output SS (mg/1) | ≤ 1.0 | ≤ 1.0 |
| Chemical cleaning | ~ 5,000mg/1 NaCIO | ~ 5,000mg/1 NaCIO |
MBR rack can be customized by your water flux.
