1.2 Ton Mini Excavator 930mm Total Width and Full Hydraulic Control
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
5-14 work days
Brand:
Hightop
Product Description
1.2 ton Mini Excavator HT12G
Product Features
- Kubota Z482 Engine: Provides powerful power output and stable operation under various working conditions.
- Full Hydraulic Control with Pilot System: Advanced pilot control system ensures more accurate operation, faster response, and improved work efficiency.
- Compact Chassis Design: Total width of only 930mm with tail turning radius of 820mm, providing excellent maneuverability in narrow spaces.
- Enhanced Structural Protection: Complete surface treatment including shot blasting, pickling, phosphating, and spraying for increased paint adhesion, durability, and corrosion resistance.
Technical Specifications
| Model | HT12G | Maximum Excavation Height | 2455mm |
| Engine | Z482 Kubota | Maximum Dumping Height | 1620mm |
| Transportation Length | 2380mm | Maximum Digging Depth | 1850mm |
| Total Width | 930mm | Maximum Excavation Distance | 2920mm |
| Upper Width | 940mm | Minimum Radius | 1510mm |
| Total Height (Cab Roof) | 2270mm | Maximum Height at Minimum Turning Radius | 1930mm |
| Standard Track Shoe Width | 180mm | Work Quality | 900kg |
| Track Gauge | 750mm | Bucket Capacity | 0.02m³ |
| Bulldozer Blade Height Above Ground | 110mm | Form of Working Device | Backhoe |
| Bulldozer Shovel Pushes Excavation Depth | 195mm | Gradeability | 30 degrees |
| Tail Turning Radius | 820mm | ||
| Track Grounding Length | 890mm | ||
| Track Length | 1235mm |
Product Gallery
