1. NO SENSOR & LIMIT SWITCH
Innovative design which doesn’t need any sensor and limit switch.All control by drive unit precisely.
Four main parts only, mechanical, motor, control unit, and power supply.

2. MAINTENENCE FREE
DC Brushless Servo motor doesn’t need a carbon brush while brush motor requests you replace the carbon
brush in a certain time. Galvanized and powder-coated parts are anti-rust ensuring long-term usage.
And no other smaller parts need to be maintained too.

3. 24/7 CONTINUS OPERATION
With a very smooth and quiet motorized drive mechanism, Open and close very stable, offer maximum reliability at fast speeds, in 7*24 hours non-stop usage.

4. SPEED ADJUSTABLE
Our DC servo barrier gate allows you to set opening and closing speeds according to requirements. The shorter the arm, the faster the speed can be set.

5. AUTO-REVERSE FUNCTION
When the arm falls and meets obstacles, the arm will auto-reverse to prevent further damage.

6. MULTIPLE INTERFACES
* Wire Control Signal Input (open&close&stop)
* Infrared Photocells
* Loop Detector
* R&G Light signal (Up&Down Limit signal output optional),
* Can be used for counting purposes also
* Arm Presence Detection(Optional)
* RS485 Communication(Optional)
* More If Required

7. EASY INTEGRATION
An access Reader or Push button or remote controller can be used to trigger the barrier gate to open via a
simple dry contact signal. After the delay timer has elapsed, barrier gate will close automatically by itself in a certain
time(optional function)

8. USER FRIENDLY
Motorized arms provide comfortable passage while maintaining a high level and high density of car flow
management, such as in toll gates.

9. AUTO-RECOVERY
When power off, the barrier arm can be lifted up manually for a free exit. When the power supply is restored,
The barrier gate will automatically return to the closed position.

10. Auto Testing Mode
The control board can set auto-testing mode.
