Aluminum PC Outdoor Sport Court Lighting , Multipurpose Indoor Court Lighting
Price:
Negotiable
MOQ:
1PC
Delivery Time:
15-20days
Brand:
LUXSUN
Product Description
OPSPORT SERIES LED 1800W/2040W IK09 IP66 LED SPORT LIGHTING, HIGH MAST LIGHTING
Opsport is a highly efficient floodlight for sports and large area lighting. Available with a wide range of lumen outputs from47,340lm –299,880lm, multiple distribution types and accessories enable efficient and accurate designs achieving the highest levels of uniformity. Every aspect of this product is highly engineered and built to last in the harshest of environments
Main Features
- High brightness
- Energy efficiency
- Long lifespan
- Durability
- Directional lighting
- Instant lighting
- Dimmability
Product Advantages
● Up to 151lm/w system efficacy
● Lumileds LED chips and Inventronics Driver package
● Separate driver box for heat dissipation, remote driver and driver on fitting installation optional
● 3000K, 4000K, 5000K and 5700K CCT
● 320W-2040W, 47,040lm–299,880lm Lumen Package
● 10kv/20kv surge protection optional.
● 1-10V/DMX, DALI dimming available,
● IP66 and IK09
● Full range of accessories available inc. laser scope for aiming and anti-glare hood shield.
● High Efficient Symmetric and Asymmetric Optics:12°/16°/30°/60° & 25°x130° /40°x130° /60°x130° /AS-L /AS-R
● CE ENEC CB SAA certified
● 5 Years Warranty
Product Parameter
| Part No. | LUX-SP-320/480/550 | LUX-SP-600/680 | LUX-SP-800/960/1100 | LUX-SP-1200/1360 | LUX-SP-1440/1650 | LUX-SP-1800/2040 |
| One Module | One module | Two modules | Two modules | Three modules | Three modules | |
| Power Range | 320W/480W/550W | 600W/680W | 800W/960W/1100W | 1200W/1360W | 1440W/1650W | 1800W/2040W |
| Input Voltage | AC100-277V 50-60Hz,PF>0.97 | |||||
| Angle | 12°/16°/30°/60°/25*130°/40*130°/60*130°/ | |||||
| Luminous Efficacy | Up to 150lm/W(±5%) | |||||
| CCT | 5000K(3000K,4000K,5700K, available) | |||||
| CRI | >70(>80,>90available) | |||||
| Dim options | 0-10v/Dali/DMX | |||||
| IP | 66 | |||||
| Operating temperature | -30°C to + 45°C | |||||
| LED Chips | Osram(12°/16°) & Lumileds 5050 (60°/25*130°/40*130°/60*130°/NB40) | |||||
| Driver | INVENTRONICS | |||||
| Color | BLACK & GREY | |||||
| Lifespan | >10,2000 hours lifespan to L70 | |||||
| Warranty | 5 years | |||||
