Used Tektronix DPO7054 Digital Phosphor Oscilloscope with 500 MHz Bandwidth 4 Channels and 20 GS/s Sample Rate

The Tektronix DPO7054 Oscilloscope is a real-time digital phosphor oscilloscope and represents the industry's premier solution for addressing challenging signal integrity issues faced by designers during verification, characterization, debugging, and testing of sophisticated electronic designs.

This oscilloscope delivers exceptional performance in signal acquisition and analysis, operational simplicity, and unmatched debugging tools to accelerate day-to-day tasks. It features the largest screen in the industry and an intuitive user interface that provides easy access to maximum information.

• 500 MHz Bandwidth Model for Serial and Digital Applications
• Up to 500 Megasamples Record Length with MultiView Zoom™ Feature for Quick Navigation
• Up to 40 GS/s Real-time Sample Rate on One Channel and up to 10 GS/s on All Four Channels
• Event Search and Mark to Find Specific Events in the Entire Waveform
• >250,000 wfms/s Maximum Waveform Capture Rate
• Up to 310,000 Waveforms per Second with FastFrame™ Segmented Memory Acquisition Mode
• Communications Mask Testing
• MyScope® Custom and Right Mouse Click Menus for Exceptional Efficiency
• User-selectable Bandwidth Limit Filters for Better Low-frequency Measurement Accuracy
• 64-bit NRZ Serial Pattern Trigger for Isolation of Pattern-dependent Effects up to 1.25 Gb/s
• 12.1" XGA Display with Touch Screen
• Pinpoint® Triggering provides the Most Flexible and Highest Performance Triggering, with Over 1400 Combinations to Address Virtually Any Triggering Situation
• Clock Recovery from Serial Data Streams
• OpenChoice® Software with XP OS enables Built-in Networking and Extended Analysis
• Low-speed Serial Protocol Triggering and Decode (I2C, SPI, RS-232, CAN, LIN, and FlexRay)
• Technology-specific Software Solutions provide Built-in Domain Expertise for MIPI® D-PHY, Ethernet, USB 2.0 Compliance Testing, Jitter, Timing, Eye Diagram, Power, DDR Memory Bus Analysis, CAN, LIN, and FlexRay Network Design

• Signal Integrity, Jitter, and Timing Analysis
• Debugging and Compliance Testing of Serial Data Streams for Telecom and Datacom Industry Standards
• Verification, Debug, and Characterization of Sophisticated Designs
• Investigation of Transient Phenomena
• Low-speed Serial Bus Design (I2C, SPI, RS-232, CAN, LIN, and FlexRay)
• Spectral Analysis
• Power Measurements and Analysis
