Anti Skateboard Horizontal V Cutting Machine V Groover Machine For Ornament Industry 1240
Price:
Negotiation
MOQ:
1 set
Delivery Time:
7-25 days
Brand:
SUBIERUI
Product Description
Anti-Skateboard CNC V Grooving Machine For Display Props And Ornament Industry - Model 1240
Visual Image Editing
For complex graphics, especially when both sides of plate need to be processed, two-dimensional graphics can be drawn directly by hand, visually and intuitively programmed, and the operating threshold is lowered at the same time.
Our services
Today, many enterprises must survive in international competition, and production costs will increase due to obsolete equipment, unexpected downtime, capacity problems or under-trained employees.
The company has excellent equipment and after-sales service. From project planning and start-up to production tracking and operation training, to equipment maintenance, spare parts supply and maintenance, we will provide you with a full range of services.
Visual Image Editing
For complex graphics, especially when both sides of plate need to be processed, two-dimensional graphics can be drawn directly by hand, visually and intuitively programmed, and the operating threshold is lowered at the same time.
| No. | Name | Parameter | Unit | |
| 1 | Max. Width of metal sheet | 1250 | mm | |
| 2 | Max. Length of metal sheet | 4000 | mm | |
| 3 | Max. thickness(Stainless steel) | 5 | mm | |
| 4 | Min. Thickness of metal sheet | 0.4 | mm | |
| 5 | Min.distance of the V from edge | 8 | mm | |
| 6 | Max. cutting speed of X axis | 120 | m/min | |
| 7 | Max .return speed of the X axis | 120 | m/min | |
| 8 | Max.distance of Y axis | 1250 | mm | |
| 9 | Resolution in Y1 axis | 0.001 | mm | |
| 10 | Repeated positioning accuracy | ±0.01 | mm | |
| 11 | Resolution in z axis | 0.001 | mm | |
| 12 | Repeated positioning accuracy | ±0.01 | mm | |
| 13 | Motor power | X axis | 5.5 | kW |
| Y1.Y2.Z axis | 1.0 | |||
| 14 | Overall dimension | Length | 5900 | mm |
| Width | 2000 | |||
| Height | 1550 | |||
