Indoor VHD P2.6 Full Color LED Display Screen Rental Stage Events Adverting LED Video Wall
Indoor VHD P2.6 Full Color LED Display Screen Rental Stage Events Adverting LED Video Wall
Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen
Specifications:
| NO.: | Product name | P2.604 high definition led display |
| 1 | Pixel Pitch(mm) | 2.604mm |
| 2 | Pixel configuration | 1R1G1B/SMD2121 Black lamp |
| 3 | Pixel density | 147465dots/m2 |
| 4 | Brightness | 1000cd/m2 |
| 5 | Module size(W*H) | 250*250mm |
| 6 | Module Resolution (W*H) | 96dots x96 dots |
| 7 | Module weight | 600g |
| 8 | Cabinet size (W*H) | (500mm×500mm)or(500mmx1000mm) |
| 9 | Drive IC | MBI5153 |
| 10 | Drive mode | 1/32scan |
| 11 | Viewing Angle(V/H) | 140 ºC |
| 12 | Grey Scale | 65536 degree |
| 13 | Life time | >100,000 Hours (80%) |
| 14 | MTBF | >50,000 Hours |
| 15 | Operating Voltage | AC110V/220V±10% |
| 16 | Screen Power Consumption | Max: 900w/m2; Average:300w/m2 |
| 17 | Input Power Frequency | 50/60Hz |
| 18 | Operating temperature | -30--60ºC |
| 19 | Humidity | 10%-95% |
| 20 | Refresh Rate | ≥1920HZ |
| 21 | Control Method | Synchronized with computer monitor |
| 22 | Color Temperature | 6500K-9500K |
| 23 | LED control system | LINSN,Nova-star,Colorlight is selectable |
| 24 | Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km |
| 25 | Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
| 26 | Systems Operating Platform | Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 |
Features:
1. Light weight and super thin,80mm thickness only 6.8kgs per panel for 500x500mm,12.5kgs per panel for 500x1000mm, easy to move
2. Rental design cabinet, easy to install and dismantle with fast lock and aviation plugs,and with many different outlooking for choosing
3. High refresh rate up to 3840Hz,and high contrast ratio of 5000:1
4. Packaged with flight case, convenient to be collected and transportation,better for rental use
5. Suit for both outdoor and indoor pixel pitch 2.6mm,2.976mm,3.91mm and 4.81mm,also can be with front and rear maintenance,and can be curved shapes with angle adjusters.
Packing and Shipping:
Packing: Anti-shaking wooden cabinet/Air flight case/strong carton
Shipping port: Shenzhen, China
Shipping way:Air;Express;Ocean;Land Transportation
Delivery time: 7-15 working days after confirm receipt payment in advance.
Long working life: In the Maintenance period, free of all maintenance charge.After maintenance period only charge the material costs fees.
Why Choose Us?
Support ODM& OEM
Reasonable price with best quality
Clear cost initially to save your time and money.
Superproduct quality, quick and professional services
Recommend the best proper solution for your LED project.
FAQ
1. Is the product customizable?
Yes, we can customize the product according to customers' requirement, you just need to provide the project details.
2. What is your terms delivery?
EXW, FOB, CFR, CIF, DDP, DDU...
3. Do you test all your goods before delivery?
Yes, we have 100% test before delivery.
4. What certificates can you provide?
CE, RoHS, FCC, ETL, CB
Our Services
1. The price depends on the quantity.We can offer you the best competitive price with the same even better quality.
2. Good after sale service: We can response in time if customers have questions about the installation , usage and maintenance ect.
3. Your inquiry will be replied by well-trained and experienced staffs in 24 hours.
4. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
5. Help you design OEM&ODM or any your customized lightings and put into production.
6. Distributorship are offered for your unique design and some our current models
7. Your sales area, ideas of design and all your private information will be well protected
