230i Water Cooled Fronius Welding Machine Fronius Tig Welding Machine
Fronius iWave 230i Water-Cooled TIG Welding Machine Package
TECHNICAL SPECIFICATION
| Mains Voltage | 1x120 Vac (-20%/15%) | 1x120 Vac (-20%/15%) | 1x120 Vac (-20%/15%) |
| GeneratorRequirement | 2.4kw | 3.2kw | 6.2kw |
| Mains cable | (included) | (included) | (included |
| Voltage rangeMIG | 10.1-19.2 Vdc | 10.1-19.2 Vdc | 10.1-19.2 Vdc |
| Current range STICK |
10-100A |
10-120A | 10-190A |
Fronius iWave 230i (Magicwave) Water-Cooled TIG Welding Machine
WHAT'S IN THE BOX?
MagicWave 230i MV/B TIG Welding Machine (4,075,219.631)
MagicWave 230i Water-Cooler Assembly CU 600T (4,048,010,630)
TIG Torch Assembly THP 300i w (4,051,322)
Ground cable and Ground Clamp (43,0004,0161)
US Style Gas Adapter (42,0001,3541)
Flow meter (42,0440,0002)
Power Adapter 6-50P (42,0440,0227)
TIG Consumables Kit (44,0350,1558)
1 x Fronius Welding Cooling Liquid FCL10 (1.32 Gallon) for Water-Cooled Fronius Machines (40,0009,0180)
120v Power Cable NEMA 5-20 (43,0004,5668)
120v Power Cable NEM5-15 (43,0004,5666)
220/230v Power Cable NEMA L6-20 (43,0004,5801)
Electrode holder for stick welding is sold separately.
Wired TIG foot pedal is sold separately but availabe (4,046,110)
FREQUENTLY ASKED QUESTIONS:
Q. Using the standard TIG Torch that comes with this machine package, can I use standard TIG consumables?
A. Yes, standard "CK Style" consumables thread on this TIG Torch without any issues. You will need to use a Fronius back cap though.
we do our very best to bring you state-of-the-art welding equipment. The Fronius MagicWave 230i AC/DC Water-Cooled TIG Welder is yet another industry-shaking TIG welding machine by the guys and girls over at Fronius.
MAXIMUM MODULARITY WITH THE iWAVE TIG WELDING SYSTEMAdaptable and expandable based on a modular approach: thanks to the standardized interfaces, you can mold iWave perfectly to meet your requirements. Customization not only encompasses system configuration but also the range of functions on the welding system – and is even possible at a later date.
