Car Driveway Lawn HDPE Plastic Grass Grid Paving Reinforcement
Plastic Car Driveway Lawn Paving Reinforcement Planting Paddock Mats Horse Grass Paver Grid
Reinforcement Planting Paddock Mats Horse Grass Paver Grid Product Description
Plastic geogrid grass grid is made from HDPE (high-molecular polyethylene) with fiber and age resistor, using high pressure to inject plastic to form bee nest-like shaped shell, with stereo space and support level.
Grass grid uses a modified high molecular HDPE and PP as raw material, Material adopt high pressure injection forming technology to suppress the nest bee continuous shell, three-dimensional space and certain support height and strength, green environmental protection, completely Recyclable. It realizes a perfect combination of parking lots with lawn. Grass paver has good properties pressure-resistant, abrasion resistance, impact resistance, aging resistance, corrosion resistance, etc. It enhances the quality and saves investment. The flat lapping type is unique. It can save labor, fast, telescopic joint regulation.
2.Technical Data:
| Product Name | Plastic Grass Paver | ||
| Model | GPP-38 | GPP-48 | GPP-68 |
| Size(mm) | 410×390×38 | 410×390×48 | 410×390×68 |
| 500×500×38 | 500×500×68 | ||
| Pressure Strength | 160ton/sqm-250ton/sqm | ||
| Material | HDPE ( high-density polyethylene ) | ||
| Product Type | Virign material and Recycled Material | ||
| Durability | at least 4 years in neutral ground of 4 < pH < 9 | ||
| Working Temperature | Apply in temperature of -10ºC to 50ºC | ||
| Anti HCL | 30%x24h, no visible change | ||
| Thermal Aging | 70ICx24h, no visible change | ||
| Anti UV | UPE>30 T(UVA)AV<5%, qualified | ||
How to install?
1. Start in corner of the project area with male tabs of first grid facing towards the center of the area
2. Line up female slots of next grid over male tabs of the first grid.
3. Lock grid into its place.
4. Repeat until the area is covered with a connected grid.
5. Gravel fill: Fill the grid with the desired aggregate to top of the grid.
6. Lightly compact to settle.
7. Grass fill: Fill the grid with soil and seed.
Features
1) Simple structure in linear type ,easy in installation and maintain.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high autoimmunization and intellectualization, no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Application
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Geogrid,Geotextile,Geocell,Geomembrane,Geocomposite,Spunbond Nonwoven Fabric
