VHP Clean Room Equipments Sterilization Chamber With Three Levels Of Authority Management
Stainless Steel VHP Sterilization Chamber With Three Levels Of Authority Management
Stainless Steel VHP Sterilization Chamber With Three Levels Of Authority Management
Technical Parameters & Specifications
| Item | Technical Specification |
| Material | SUS304/316L Stainless Steel |
| Application | Pharmaceuticals, Food & Beverage, Electronics |
| Structure | Fully Enclosed |
| Sterilization Time | <120 min. |
| Vaporization Power | Clean Compressed Air |
| Sterilization Efficacy | 6-log |
| Sterilization Media | 30% Medical Grade H2O2 |
| Maintenance Mode | Side Access/Up-Down Access |
| Inlet Air Purification | H14 |
| Cycling Mode | Direct Exhaust |
| Validation Document | 4Q/FAT/SAT |
| System Monitoring | Increase concentration |
| Soft System | Display the current step, remaining time and working status of main parts, time setting, system parameter setting, alarm information, online data monitoring, manual and automatic switching, sterilization batch input, validation information, PDF report, formula management |
Vaporized Hydrogen Peroxide
The vaccine industry is generally used for delivery:
- sterile gloves and eye masks;
- Sterile flask and lid;
- Aseptic medium; Record;
- Virus strain;
- Embryo eggs;
- Fermentation tank etc.
Chamber air tightness test:JG/T 382-2012“Pass box”( - 500 Pa pressure maintaining 20 min,≤ - 250 Pa)
HEPA leak detection: in situ scanning leak detection can be done for high efficiency of air supply and exhaust
Cleanliness: static class A
Operation Principle
Chamber air tightness test:JG/T 382-2012“Pass box”( - 500 Pa pressure maintaining 20 min,≤ - 250 Pa)
HEPA leak detection: in situ scanning leak detection can be done for high efficiency of air supply and exhaust
Cleanliness: static class A
Product Description
- Reserved foundation pit, equipment internal ground and ground level
- Door body multi-point fixed, high strength, no sagging
- Split window, chamber situation can be clearly seen
- If there is a dry/wet heat sterilization chamberet around, color steel plate isolation is recommended.
Characteristic & Features
-
Sterilization process <120min. to realize multiple sterilization operations one day.
-
Emergency Stop.
-
Decomposition filter can effectively reduce the concentration of VHP remain Reduce the impact on environment and personnel.
-
Very low hydrogen peroxide consumption.
Engineering Drawing
Sterilization Process & Vaporizer Schematic Diagram
| Serial NO. | Name |
| 1 | Evaporation system |
| 2 | Exhaust system |
| 3 | Air supply system |
| 4 | Exhaust duct |
| 5 | The sterilization chamber |
| 6 | Commodity shelf |
| 7 | Electric mounting bracket |
