Multifunctional AC Servo Drive , Practical Programmable Servo Motor
China Manufacture P100 Series Servo Drive/ Servo Control/AC Drive/ Frequency Inverter/Servo Frequency Inverter 22v 480v
Pulse Type AC Servo System
Product features
Strong internal motion control functions which can realize position, speed,torque,homing controlling modes. It also supports I/O control and standard Modbus RTU protocol. It can replace PLC partly, which helps to save cost.
System Wiring Example
Drives Of P100S Series As Example:
Drives Of P300 Series As Example:
Dimension
Pecification
Products images
EtherCAT Bus Field AC Servos
Feature Introduction
System Wiring Example
Dimension
Drive Specification
Why choose K-Drive variable frequency drive?
In the trend of advocating smart and simple industrial automation, environmentally friendly products, value-added solutions, K-Drive, as one of the world's leading drive manufacturers aggressively investing in R&D, production, and continuous quality improvement, is well positioned to provide its customers with technology-driven, performance-outstanding products such as VFDs, wind power converters, servo drives, HEV/EV drives, helping its customers save energy and increase industrial productivity with sustainability on the one hand, and enhancing their entire value-chain quality, delivery, and services on the other hand.
K-Drive VS Other brands
| Performance | Common brands | K-Drive |
|---|---|---|
| Applicable motors | Asynchronous motors | Asynchronous /synchronous motors |
| Starting torque | 2.0Hz, 150% (sensor-less vector control) 0Hz, 180% (closed-loop vector control) | 0.5Hz, 180% (sensor-less vector control) 0Hz, 200% (closed-loop vector control) |
| Speed adjustable range | 1:100 (SVC), 1:1000 (VC) | 1:200 (SVC), 1:1000 (VC) |
| Ambient temperature (no derating required) | -10-40ºC | -10-50ºC (for most of the models) |
| Rated input voltage | 208VAC-400VAC | 208VAC-480VAC |
| Communication | Modbus RTU//ASCII | Modbus RTU//ASCII Profibus-DP, CANopen, etc. |
| Position control (fixed length, or angular positioning) | × | √ |
| Field weakening control | × | √ |
| Autotune online | Online | Online & Offline |
| Short-time ramp-up | Trip | No trip |
| Customized features (software and/or hardware) | Unprocurable or no experience | Procurable with rich experience |
Production
In production, rigorous quality control is implemented on components, circuit boards, and the finished goods, assuring products without defects.
How to connect ac servo?
Connecting an AC servo typically involves the following steps:
-
Power Supply: First, you need to connect the power supply to the servo motor. Most AC servo motors require a three-phase power supply. Make sure to check the manufacturer's specifications for the correct voltage and frequency.
-
Encoder Feedback: Next, connect the encoder feedback device to the servo drive. The encoder provides position and speed feedback to the servo drive, which in turn controls the motor's movement.
-
Servo Drive: Connect the servo drive to the motor. The servo drive converts the incoming control signals into a form that can be used to drive the motor.
-
Communication: Depending on the servo motor and drive, you may need to establish a communication link between the servo drive and your control system. This allows you to send commands and receive feedback from the servo motor.
-
Wiring: Finally, connect all the wiring and make sure that the connections are secure and properly insulated.
It is essential to follow the manufacturer's instructions carefully when connecting an AC servo motor. If you are unsure about any of the steps involved, seek the help of a qualified technician or contact the manufacturer's customer support for guidance.
