Brand New Emerson KJ2201X1-HA1 Power Supply Module In Original

Description:

Power Specifications:

Input Power 30 VDC

Max current: 30 mA per channel for circuitsbetween terminals A and B.1 A per channel for circuits between terminals A and C.

Environmental Specifications:

AmbientTemperature:  -40 °C to +70 °C

Shock 10 g half-sine wave for 11 msVibration 1 mm peak to peak from 2 to 13.2 Hz;0.7 g from 13.2 to 150 Hz

AirborneContaminants: ISA-S71.04 –1985 AirborneContaminants Class G3

Relative Humidity: 5 to 95% non-condensing

Note: Refer to the product label for serial numberand location and date of manufacture.

Warning:

This product has specific instructions forinstallation, removal and operation in hazardousareas.

Refer to document 12P2046, DeltaV™Electronic Marshalling Digital Automation System(CHARM I/O Subsystem) Zone 2 InstallationInstructions". Other installation instructions areavailable in the "DeltaV™ S-Series and CHARMsHardware Installation" manual.

Removal and Insertion:

This unit cannot be removed or inserted with systempower energized.Maintenance and Adjustment

This unit contains no user-serviceable parts andshould not be disassembled for any reason.Calibration is not required.
