340HP 6x4 8000 Litres Sewer Suction Vehicle DONGFENG SHACMAN With High Pressure Flushing
DONGFENG SHACMAN 6x4 340HP 8000 Litres Sewage Suction Truck Fecal Sewer Cleaning Tank Truck With High Pressure Flushing
Product description
The sewage suction vehicle is a new type of sanitation vehicle that collects, transfers, cleans and transports sludge and sewage to avoid secondary pollution.
The sewage suction vehicle can be self-priming and self-discharging, with fast working speed, large capacity, and convenient transportation. It is suitable for collecting and transporting feces, mud, Liquid substances such as crude oil.
The sewage suction truck adopts the vacuum pump of the domestic leading sewage suction truck, which has a large suction force and a long suction distance. It is especially suitable for the suction, shipment and discharge of sediment in the sewer, especially for sewer mud, silt, stones, bricks, etc. larger objects such as blocks
|
Driving Style
|
Right(Left) Hand Driving | |||
|
Truck Model
|
ZZ1257N4657A | |||
|
Tank Details
|
Vacuum Pump | Jurop PN84D, Italian Brand | ||
| Tank Volume | 12m3 | |||
| Material | Q235, 6mm thickness | |||
| Water Tank | 500L with AR XWL50.15N Water Pump | |||
|
Truck Dimension (L x W x H)mm
|
10868x2550x3200mm | |||
|
Approaching angle/Departure angle(°)
|
32/15 | |||
|
Overhang(front/rear) (mm)
|
1578/2690 | |||
|
Wheel base (mm)
|
4600+1400 | |||
|
Engine (Steyr technology, made in China) |
Model | WD615.47 | ||
|
Fuel type
|
Diesel | |||
|
Horse Power
|
336HP | |||
|
Emission
|
EURO II | |||
|
Transmission
|
Model | HW19710, 10 forwards and 2 reverse | ||
| Brake system | Service brake | Dual circuit compressed air brake | ||
| Parking brake | spring energy, compressed air operating on rear wheels | |||
| Auxiliary brake | Engine exhaust brake | |||
| Steering system | Model | Germany type, hydraulic steering with power assistance | ||
|
Front axle
|
HF7 | |||
|
Rear axle
|
ST16 axle | |||
|
Color
|
Optional | |||
|
Tyre
|
12.00-20 tire, 10 +1 spare tire | |||
|
Cab
|
HW76 cab, one sleeper with air conditioner, | |||
