Product Description
1 The main drive of rig is mechanical and the four landing legs and drilling tower are hydraulic controlled. Transfer case and mud pump clutch system are air operated.
2 According to client’s requirement, the rig can carry out down-the-hole hammer drilling with USA Sullair, Japan PDSKIOOS, Sweden Atlas, China Kaishan, Hongwuhuan; can carry out air lifting reverse circulation drilling with air-water tap, double-wall drilling pipe, gas-water separator; can carry out Hydraulic DTH hammer drilling rock breaking with mud pump; can carry out core-drilling with other special drilling tools .
3 The appearance of rig is pretty. It is high efficiency because of having a larger torque of the turntable and is mainly used for water well in industry and agriculture, national defense building foundation, geological exploration, geothermic well and other foundation working, it is popular at home and abroad.
|
Drilling depth(M)
|
600 | ||
|
Drilling diameter(mm)
|
500 | ||
|
Speed of rotary table(r/min)
|
132; 15; 6; 43; 25; 14, 18(reverse) | ||
|
Torque of rotary table(KN.m)
|
7.4----52 | ||
|
lifting capacity of main winch(KN)
|
50 | ||
|
Maximum lifting capacity of main windlass(KN)
|
300 | ||
|
Single rope lifting capacity of assistant windlass(KN)
|
50 | ||
|
Maximum lifting capacity of assistant windlass(KN)
|
240 | ||
|
The lifting capacity of hook(KN)
|
320 | ||
|
Bearing capacity of drilling tower (KN)
|
360 | ||
|
The height of drilling tower (mm)
|
16232 | ||
| Drill pipe |
主杆Kelly bar(mm)
|
108×108×10500 or 7500 | |
|
钻杆Assistant pipe (mm)
|
Ф89×10×9000 or 6000 | ||
|
3NB-130 mud pump
|
Theoretical flow (L / min)
|
1000 | |
|
Rated pressure (Mpa)
|
5 | ||
|
Input power (kw)
|
90 | ||
|
Truck chassis |
Drive form
|
8×4 | |
|
Engine |
Model
|
SINOTRUK .WD61569 Euro II | |
| Rated power(KW r/min) | 247/2200 | ||
|
Horsepower
|
336HP | ||
|
Size (L*W*H)(mm)
|
11510*290*2800 | ||
| Drilling diesel engine |
model
|
Cummins 6BTA5.9-C180-Ⅱ | |
|
Rated power(kw)
|
132 | ||
|
Max - torque(N.m)
|
750 | ||
| Electric generator |
Model
|
MF | |
|
Rated power (kw)
|
30 | ||
|
Rated voltage(v)
|
380 | ||
|
Rated current(A)
|
27 | ||
|
Speed (r/min)
|
1500 | ||
|
Frequency(Hz)
|
75 | ||
|
The highest speed(Km/h)
|
75 | ||
|
Weight (kg)
|
32000 | ||
|
Transport size(L*W*H)(mm)
|
13500×2500×4200 | ||
