Polished YSZ ZTA Zirconia Ceramic Substrate Zirconia Alumina 1400deg

Polished YSZ ZTA Zirconia Ceramic substrate

Zirconia-toughened alumina ceramics, a particle size composition of the main component of alumina in the preparation of
ceramiccylinder liners for drilling pumps, with an average particle size of 60-70 wt% in the range of 0.8-1.0 μm and an averageparticlesize of 30-40 wt% of 1.0 -2.8μm range of two types of alumina. Add 15vol% of zirconia (containing 2 ~ 3mol% of yttriumoxide), addappropriate amount of dispersant, mix by ball milling, spray granulation, isostatic pressing, and fire in the temperature range of1550 ~ 1620 C, it can be prepared for more than 2000 hours ceramic cylinder liner,and the formingand firing yield is high, and the raw material and process costs are low. The performance of zirconia-toughened alumina ceramics is better than 99 aluminaceramics, and the price is much lower than that of zirconia ceramics.Many occasions where alumina ceramics are incompetent show a better performance-price ratio than zirconia ceramics.

Features & Advantages
1. High strength
2. High hardness
3. Wear resistance
4. Non-magnetic
5. Electrical insulation
6. Corrosion resistance in acids and alkalis
7. Modulus of elasticity similar to steel
8. Coefficient of thermal expansion similar to iron
