One Stop Green Solder mask FR-4 PCB Design Automotive PCB Assembly Bule PCB Assembly With IATF16949
One Stop FR-4 PCB Design Layout Automotive PCB Assembly Bule PCB Assembly With IATF16949
Automotive PCB Assembly Parameter
|
Order Quantity
|
1-500,000
|
|
Layer
|
1,2,4,6,up to 22 layers
|
|
Material
|
FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
|
|
PCB type
|
Rigid, flexible
|
|
Shape
|
Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
|
|
Max PCB dimensions
|
20inch*20inch or 500mm*500mm
|
|
Thickness
|
0.3~3.0mm
|
|
Thickness tolerance
|
± 10%
|
|
Copper thickness
|
1OZ 2OZ 3OZ
|
|
Copper thickness tolerance
|
± 0.25oz
|
|
Surface finish
|
HASL, Imm Gold, Imm Tin, OSP etc
|
|
Solder mask
|
Green, red, blue, black, etc
|
|
Silk screen
|
White, black, or negative, etc
|
|
Silk screen min line width
|
0.006'' or 0.15mm
|
|
Min drill hole diameter
|
0.01'',0.25mm.or 10 mil
|
|
Min trace/gap
|
0.076mm or 4mil
|
|
PCB cutting
|
Shear,V-score,tab-routed
|
Types of Automotive PCB
Several PCB varieties are designed to withstand automotive environments while meeting functionality needs. Common types include:
Ceramic PCBs
Ceramic printed circuit boards use ceramic substrates like aluminum oxide or aluminum nitride that provide electrical insulation even at high temperatures along with thermal conductivity. This makes them well-suited for high-power automotive electronics.
HDI PCBs
High-density interconnect PCBs incorporate finer lines and spaces, smaller vias, stacked microvias, and often blind/buried vias. HDI allows greater component density and trace routing for space-constrained engine control units and infotainment systems.
High Frequency PCBs
High frequency boards with RF materials like PTFE or ceramics are employed for radar systems, collision avoidance, satellite connectivity, and wireless communications demands. Careful impedance control and tuning ensures signal integrity.
Metal Core PCBs
PCBs with aluminum or copper core base provide enhanced thermal conductivity to dissipate heat from high-power components. This assures reliable operation of traction inverters, motor drives, battery pack control, etc.
Get a Quote for your Automotive PCB
Please supply us your files in Gerber,send us your BOM, quantity information and the turn around time you need.
We will run a DFA/DFM analysis on your documents and get back to you with our report and quote.
