IP67 M19 Connector 4 Pin Waterproof Female Connector For industrial Solder Cable
Price:
$2.20/pieces 2-99 pieces
MOQ:
10
Delivery Time:
Negotiable
Brand:
SHANGWEN
Product Description
Factory Sales M19 Series Quick Self Locking System Industrial 4 Pin Female Plug Connector
Products Description
SW19 Self-locking series-4 Pin connector
M19 series is an industrial connector, which includes male plug, female plug and male socket.
There are two locking methods:
1. Push-pull self-locking connection
2. Plastic screw connection, both locking design is very reliable.
The material selection of the inner core uses gold-plated pin, which is conducive to the stable passage of the current. A variety of cores can be selected, making its application field more extensive.
The cable skin is molded by a plastic wrap mold. All materials comply with environmental RoHS standards, and passed CE,UL,FCC and other multinational certification. Male coordinate with waterproof apron, the waterproof grade of the connector up to IP67.
Product features
1) Advanced structure: Self-locking
2) Mutiple pin:2,3,4,5,6,7,8,9 to 36 pins could be choosed
3) Contact pin: Screw cable,soldering cup and crimp available
4) Assembly: wire to wire type(no cable),wire to wire by overmolding, wire to board
5) Black,blue,white and yellow color supported
6) Different cable length could be customized
1. Electrical parameters
| Contacts NO. | 2+PE |
| Rated current | 20A |
| Rated voltage | 250V AC |
| Contact resistance | ≤5mΩ |
| Dielectric strength | 4000V DC |
| Insulation resistance | ＞1000MΩ |
2. Mechanical parameters
| Service life | ＞1000 times |
| Power line | 2.5mm²(8mm - 12mm) |
| Wire stripping length | 7-8mm |
| Type of teminals | Screw type clamping units solder termination |
3. Material and environmental parameters
| Shell | PA |
| Contacts | Cu alloy |
| Contact surface | Ag |
| Flame-retardant grade | UL94-V0 |
| Protection grade | IP44 |
| Temperature range | -30°C to +80°C |
