Fiber Glass Deep Pleat HEPA Filter Pleated Panel Air Filter With Aluminum Foil Separation
Deep Pleat HEPA Filter Aluminium Frame Filter For Ventilation System
Specification
|
item |
value |
|
Applicable Industries |
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
|
Video outgoing-inspection |
Provided |
|
Machinery Test Report |
Provided |
|
Warranty of core components |
Not Available |
|
Condition |
New |
|
Efficiency |
99.99% |
|
Porosity |
0.3um |
|
Place of Origin |
China |
|
Province |
Sichuan |
|
Brand Name |
TRAIRF |
|
Dimension(L*W*H) |
customization |
|
Weight |
4KG |
|
Warranty |
Unavailable |
|
Type |
Deep Pleated Air Filter |
|
Material |
Fiber Glass with aluminum foil separation |
|
Frame |
Aluminium Alloy , Galvanized, Stainless steel |
|
Color |
Silver |
|
Initial Pressure |
220Pa |
|
Work Temperature |
80℃ |
|
Humidity |
80% |
Product Parameter
|
Model |
Outside Dimensions(mm) |
Rated air flow(m³/h) |
Initial Resistance(Pa) |
Efficiency(class) |
|
TR-YGB-1 |
305*305*150 |
250 |
≤220 |
≥99.99 |
|
TR-YGB-2 |
320*320*220 |
400 |
≤220 |
≥99.99 |
|
TR-YGB-3 |
484*484*150 |
600 |
≤220 |
≥99.99 |
|
TR-YGB-4 |
484*484*220 |
1000 |
≤220 |
≥99.99 |
|
TR-YGB-5 |
726*484*220 |
1500 |
≤220 |
≥99.99 |
|
TR-YGB-6 |
968*484*220 |
2000 |
≤220 |
≥99.99 |
|
TR-YGB-7 |
610*610*150 |
1000 |
≤220 |
≥99.99 |
|
TR-YGB-8 |
915*610*150 |
1500 |
≤220 |
≥99.99 |
|
TR-YGB-9 |
1220*610*150 |
2000 |
≤220 |
≥99.99 |
|
TR-YGB-10 |
630*630*220 |
1600 |
≤220 |
≥99.99 |
|
TR-YGB-11 |
945*630*220 |
2400 |
≤220 |
≥99.99 |
|
TR-YGB-12 |
1220*630*220 |
3200 |
≤220 |
≥99.99 |
|
TR-YGB-13 |
610*610*292 |
2200 |
≤220 |
≥99.99 |
|
TR-YGB-14 |
915*610*292 |
3300 |
≤220 |
≥99.99 |
|
TR-YGB-15 |
1220*610*292 |
4400 |
≤220 |
≥99.99 |
* Customizable Size
