ABS Plastic Frame Microfine Glass Media 24x24x12 V Bank Filter HEPA Air Filter
ABS Plastic Frame Microfine Glass Media 24x24x12 V Bank Filter HEPA Air Filter
OVERVIEW :
V BANK Hepa Air Filter is mainly used for filtration of more than 0.5μm dust particles, multi- V Mini-pleat design with large filtration area, low resistance, long service life, the use of waterproof ultra-fine glass fiber media, polypropylene plastic frame can be completely incinerated, and mounting flange frame is interchangeable with bag filter.
Material and performance
|
Frame |
ABS Plastic |
|
Filter medium |
Fiberglass(mini pleated) |
|
Max. temperature |
85°C. |
|
Max. humidity |
80%RH |
SPECIFICATIONS:
| Model | Dimensions(mm) | Airflow(m³/h) | Initial Resistance(Pa) | Efficiency(%) |
| TR-WYG-1 | 287*287*292 | 800 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-2 | 490*287*292 | 1200 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-3 | 490*490*292 | 2000 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-4 | 592*490*292 | 2000 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-5 | 592*490*292 | 2700 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-6 | 592*287*292 | 1600 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-7 | 592*592*292 | 2400 | ≤125 | 95(F8)/99(F9) |
| TR-WYG-8 | 592*592*292 | 3200 | ≤125 | 95(F8)/99(F9) |
*Customization is available.
Introduction:
Ventilation filter f8 f9 (air conditioner filter hvac ahu) is made of high strength glass fiber with gradual density. Low compressibility keeps its shape and makes fiber purified air effectively. It can absorb the excess particles during paint-spraying operation and reduce pollution to the environment, make the exhausted air more environmental-friendly and inner circulating air more clean.
Characteristic:
1. Microfine fiberglass filter media
2. Largeer air flow
3. Lower resistance
4. Higher dust holding capacity
5. Longer service life
6. High Quality Air Filters Havc,Air Filter Fiberglass,v-bank air filter manufacturer
