System Fiberglass Air Filter Media Roll Floor Filter For HVAC Air Condition
System Fiberglass Air Filter Media Roll Floor Filter for HVAC Air Condition
Product Description
Fiberglass paint stop filter media rolls, also called the Spray Booth Filter,is a kind of industrial air filters for painting rooms and other workplaces required high air quality .
It's especially suitable for automotive/furniture paint spray booth, coating production line, etc, widely applied to filtration of high quality surface painting with the feature of high arrestance, high efficiency in absorbing extra particle during the course of painting, making air pressure more equally.
Product Parameters
| Model | Outside dimensions(mm) | Rated air flow(m³/h) | Initial resistance(Pa) | Efficiency(class) | Model of filter media | |
| TR-CX-P1 |
295×295×10/20mm 12"×12" ×1/2"/1" |
800m³/h | 25-50pA | 80% -95% weight |
G2
G3
G4
|
Nylon nets Early effect filter cotton Corrugated aluminium nets |
| TR-CX-P2 | 495×295×10/20mm 20"×12" ×1/2"/1" | 1300m³/h | ||||
| TR-CX-P3 | 495×495×10/20mm 20"×20" ×1/2"/1" | 2200m³/h | ||||
| TR-CX-P4 | 595×295×10/20mm 24"×12" ×1/2"/1" | 1600m³/h | ||||
| TR-CX-P5 | 595×495×10/20mm 24"×20" ×1/2"/1" | 2700m³/h | ||||
| TR-CX-P6 | 595×595×10/20mm 24"×24" ×1/2"/1" | 3200m³/h | ||||
Application
1. Clean rooms (suitable for use in multi layer filter filtration system)
2. Food processing industry.
3. Pharmaceutical Processing.
4. Aerospace Engineering.
5. Genetic & Biological research.
6. Bio hazard Atmosphere.
7. Laminar Flow Workstations.
8. Bio Safe Hoods (Biological Safety Cabinets).
9. Hospital Operating Theaters & Intensive care units.
10. Spray Booth and Paint Room.
11. Electronic Industry.
Delivery
There are four type shipping ways you can choose:
1. By Sea.
2.By Air.
3.By Express( DHL, TNT, FedEx, UPS, EMS)
4.By Train (China Railway Express, the line starts in Chengdu and travels through Kazakhstan, Russia and Belarus to end in Lodz )
A: We are a manufacturer with two factories, one is main manufacture filter materials,media, elements, another is main manufacture all kinds of Air Filters.
Q: Why should we choose your as a trust quality supplier especially for the first deal?
A: Firstly: We can provide you qualified products as all our products are passed strictly quality inspection before sent out.
Secondly: Competitive Price provided as raw materials are provided by our own factory.
Q: Do you have any certification to ensure the quality?
A: ISO9001; CE Certification. Company has advance quality inspection equipment.
Q: What is the international standard for air filter?
A: Euro: Pre (G1---G4), Medium (F5----F9), HEPA (H10--H14), ULPA (U15--17) American: Pre (Merv1---7), Medium ( Merve8----14), HEPA (Merv15-- -19), ULPA (Merv20)
Q: Can you send Free Sample?
A: Yes.We can offer you Free Samples and you just need to pay express charge. You also can provide your Express Account or asking your courier to pick up from our factory.
