Customized Outdoor FTTH Drop Cable G657A1 G657A2 Type Black Color
Price:
$0.03 - $0.039/meters
MOQ:
10000 meters
Delivery Time:
Negotiable
Brand:
ODM/OEM
Product Description
CABO OPTICO CFOAC-BLI-A/B-CM-01F-AR-LSZH cabo de Fibras opticas drop for Brazil
Describution:
The optical fiber unit is positioned in the centre.Two parallel Fiber Reinforced Plastics(FRP) are placed at the two sides.A steel wire as the additional strenght member is also applied. Then the cable is completed with a black or color LSZH sheath.
Application:
- All types of fiber cables with different structures
- High performance optical network operating
- High speed optical routes in buildings (FTTx)
- Application in L band
Features
1, High tensile of the diameter1.0mm steel wire meet the requirement of self-supporting and reducing the installation cost.
2, Two parallel FRP/ steel wire strength members ensure good performance of crush resistance to protect the fiber
3, Novel flute design, easily strip and splice, simplify the installation and maintenance
4, Low smoke zero halogen and flame retardant sheath
5, Single mode
6, (2.0±0.2)x(5.0±0.2)mm
7, Compliant with Telcordia GR-326-CORE specification
2, Two parallel FRP/ steel wire strength members ensure good performance of crush resistance to protect the fiber
3, Novel flute design, easily strip and splice, simplify the installation and maintenance
4, Low smoke zero halogen and flame retardant sheath
5, Single mode
6, (2.0±0.2)x(5.0±0.2)mm
7, Compliant with Telcordia GR-326-CORE specification
Specification
|
No. of cable
|
|
|
|
1/2/4/6
|
|||
|
Fiber Model
|
|
|
|
G.657A1
|
|||
|
Steel wire
|
Diameter(±0.03)mm
|
|
|
0.45
|
|||
|
|
NO.
|
|
|
2
|
|||
|
Steel wire
|
Diameter(±0.03)mm
|
|
|
1.0
|
|||
|
Outer Sheath
|
Material
|
|
|
LSZH
|
|||
|
|
Color
|
|
|
Black
|
|||
|
Cable size(±0.2)mm
|
|
|
|
2.0×5.0
|
|||
|
Cable Weight(±2)kg/km
|
|
|
|
21
|
|||
|
Allowable Tensile Strength
|
|
Short Term
|
N
|
600
|
|||
|
|
|
Long Term
|
|
300
|
|||
|
Allowable Crush Resistance
|
|
Short Term
|
N/100mm
|
2200
|
|||
|
|
|
Long Term
|
|
1000
|
|||
|
Min. bending radius
|
|
Without Tension
|
|
10×Cable-φ
|
|||
|
|
|
Under Maximum Tension
|
|
20×Cable-φ
|
|||
|
Temperature range
(℃) |
|
Installation
|
|
-20~+60
|
|||
|
|
|
Transport&Storage
|
|
-40~+70
|
|||
|
|
|
Operation
|
|
-40~+70
|
|||
