High Accuracy Benchtop LCR Meter Digital Component Tester For Semiconductors

TH2817C+ LCR Meter Benchtop Type LCR Meter Component Parameter Test Instruments LCR Meter

1. Quality Control and Manufacturing: LCR Meters are utilized in quality control processes during component and circuit manufacturing. Manufacturers rely on LCR Meters to verify that produced components and circuits meet specified requirements. By measuring and analyzing parameters, LCR Meters ensure consistent quality and reliability in the manufacturing process.

Features
■ test frequency 50Hz,60Hz,100Hz,120Hz,1kHz,10kHz,20kHz,40kHz, 50kHz,100kHz, total 10 points
■ 4.3 inch TFT liquid crystal display
■ 50Hz-100kHz, 10 typical test frequencies
■ 6-digit reading resolution
■ Maximum test speed:12.5ms, support low frequency and high speed:TX4+3ms
■ Chinese and English optional operation interface
■ 10 bins sorting, test sorting is more perfect
■ 100 sets of LCRZ instrument setting files, 10 measurements
■ Soft power switch
■ Support 110V/220V two power supply voltages
■ 10-point list scanning, support multi-frequency test sorting
■ Ultra-low signal source output offset (<100μV), meeting the needs of large inductor, common mode choke inductor test
■ Super impact protection
■ Power on state lock button;
■ Empty fixture judgment
■ Data logging function
■ Screen capture function
■ Interface function, timing, trigger delay, etc. are more complete
