Q355B Telescopic Dipper Arm For Hitachi EX200-5 20-50T Excavator
Telescopic Dipper Arm can make 14M 16M PC320D JCB205
My name is sophia from Zhonghe Machinery , our factory produce telescopic arm and different types of long arm , please contact me if you need
whatsapp/wechat:+86 18127591702
sophia@excavatorboomarm.com
As the name suggests, a telescopic dipper arm is a highly specialized, purposed-built attachment with a sophistiPCed telescopic mechanism. Your investment value of a telescopic dipper is fully realized when excavation work needs to be carried out in an extreme confined space or picking up material from a pit where a long reach front attachment still deems to be too cumbersome.
Most commonly seen solutions in overcoming such challenging situations is to employ a crane fitted with a cable operated clamshell bucket. The cycle time of this crane solutions is extremely high as compared to a hydraulic operated telescopic dipper arm with a clamshell bucket front attachment. An ingenious implementation and integration of hydraulic system with cable and sheaves make up the key integral system in operating 2 sliding elements within the outer housing.the key integral system in operating 2 sliding elements within the outer housing.
A telescopic dipper attachment for a 20 ton and 35 ton class excavator could enjoy up to 20 meter and 25 meter digging depth respectively if desired, and the beauty is, its only require very small working radius. If you are challenged by space and depth constraint at the work site, there is simply no other better option than counting on a telescopic dipper attachment.
✅ Built-in slider reduces cylinder vibration
✅One telescopic boom, one Bucket, one Bucket Cylinder,
✅One set of Lickage, other accessories
| Excavator model (ton) | bucket capacity(cbm) | bucket cylinder |
| 6T | 0.2 | 6T |
| 10-12T | 0.2 | 6T |
| 20-27T | 0.4 | 20T |
| 30-36T | 1 | 30T |
| 20-27T | 0.4-0.6 | 20T |
| 20-27T | 0.8 | 30T |
| 30-36T | 1 | 35T |
| 30-36T | 0.8 | 30T |
| 30-36T | 1 | 35T |
| 24-28T | 0.8 | 30T |
| 24-28T | 0.4 | 20T |
| 30-36T | 0.8 | 22T |
welcome to send your excavator model to us. Suitable length will be recommended.
Robust structure
1. Adopt 22-ton strong bucket cylinder
Avoid oil leakage
2.The cylinders are important, the telescopic arm for sale is leading by extrending and retracting.
1. Hydraulic hoses are made of four-layer steel wire ring.
2. The telescopic cylinder adopts double oil seals
3. Bucket cylinder hose was built-in to avoids oil leakage caused by hose vibration
Long service life
Excavator sliding boom arm is designed with longer life-span.
1. The reel adopts enlarged spring piece
2. Adopt 22-ton strong bucket cylinder
Easy to maintain
The cylinder of the excavator boom arm is long, the tube steels are long.
1. LubriPCion system for sliders help support butter easily.
2. Bucket cylinder hoses can be replaced easily, without dismantling the arm.
Avoid oil leakage
The cylinders are important, the telescopic arm for sale is leading by extrending and retracting.
1. Hydraulic hoses are made of four-layer steel wire ring.
2. The telescopic cylinder adopts double oil seals
3. Bucket cylinder hose was built-in to avoids oil leakage caused by hose vibration
Kaiping Zhonghe Machinery Manufacturing Co., Ltd. was established in 2018. It is an enterprise integrating production and trade. It specializes in customizing different types of excavator booms arms and attachments, such as excavator long arms, demolition arms, sliding arms, 2-3 section telescopic arms, tunnel arms, standard/rock buckets, grabs, ripper, etc., which are sold well in more than 60 countries and regions. The following are our advantages:
1. Covers an area of about 18000 square meters
2.Staff size 120 people.
3.Technical equipment (2 sets of plasma, CNC cutting machines, 3 milling machines, a set of precision floor boring machines, One set of chamfering and beveling machines, two large lathes/drilling machines, a large shot blasting workshop, a stress relief workshop, a large plate rolling machine, and a high -purity mixed gas supply station, etc.)
4.Our company offers customers a comprehensive production line of custom-designed, custom-made, and delivered products.
5.Prompt lead time:7-25 days
6.Annual production amount 600 sets of excavator booms
We adhere to "Merit Quality, Sincerity Management and Customer Satisfaction", honestly greet customers from home and abroad to negotiate and cooperate with us
14000㎡ Workshop
Prompt Lead Time
High-tech R&D Team
100% Service
Usually use 40GP container to load product !
Contact sophia to inquiry details !
this is my contact way directly
Sophia W/A: +86 18127591702
Mail: sophia@excavatorboomarm.com
www.excavatorrockbuckets.com
