D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM
Price:
$27 -$68/ Piece
MOQ:
1000pcs
Delivery Time:
<20 work days
Brand:
Yuanmai
Product Description
Products Description
Palisade fence pale type
The palisade fence pale can be divided into corrugated pale and angle pale. The corrugated pale has W type and D type with different structure surface.
- D section pales. Working with long bolts, are designed for boundary delineation requiring low to medium security and damage resistance.
- W section pales. with higher inherent strength and better vandal resistance, are the most used type to provide effective high security and extra protection. Fastened by short bolts, the W type palisade pales are flush against the horizon rails without flexibility.
- Angle steel pales. Bolted or welded to horizon fence rails, are suitable for general purpose applications, such as residential estates protection.
Product Paramenters
The common types of palisade fence are W pale and D pale type palisade fencing with three point on the top of the fence. Though the price of the two type is same, but the W pale type palisade fencing is more widely used type than the D pale type, additional, it is more beautiful. So we suggested our customer to choose the W pale type.
| Specification Of Palisade Fence | ||||||
| Panel size | W section Pale:70mm | Angel Rail | Post | |||
| Height | Width | Pale Thickness | Qty:Pale | Cross Rails | Square post | I Post |
| 1.8m | 2.75m | 2/2.5/3mm | 17pcs | 40×40×4mm | 60*60mm | 100×55mm |
| 2.1m | 2.75m | 2/2.5/3mm | 17pcs | 50×50×6mm | 80*80mm | |
| 2.4m | 2.75m | 2/2.5/3mm | 17pcs | 100*100mm | ||
| 3.0m | 2.75m | 2/2.5/3/3.5mm | 17pcs | |||
| W section Pale:62mm | ||||||
| 1.8m | 2.75m | 1.5/2/2.5mm | 17pcs | 40×40×4mm | 60*60mm | 100×55mm |
| 2.1m | 2.75m | 1.5/2/2.5mm | 17pcs | 50×50×6mm | 80*80mm | |
| 2.4m | 2.75m | 1.5/2/2.5mm | 17pcs | 100*100mm | ||
| 3.0m | 2.75m | 1.5/2/2.5mm | 17pcs | |||
| D Pale section:65mm | ||||||
| 1.8m | 2.75m | 1.5/2/2.5/3mm | 17pcs | 40×40×4mm | 60×60mm | 100×55mm |
| 2.1m | 2.75m | 1.5/2/2.5/3mm | 17pcs | 50×50×5mm | 80x80mm | |
| 2.4m | 2.75m | 1.5/2/2.5/3mm | 17pcs | 100x100mm | ||
| 3.0m | 2.75m | 1.5/2/2.5/3mm | 17pcs | |||
| Surface treatment: Galvanized or galvanized then powder coating finished | ||||||
| Pale head:Can be do single pointed, triple pointed, square tops, round and notched tops or rounded only. |
||||||
Exhibition
Detail
The base material of zinc steel guarderail profile is high temperature hot dipping zinc material, hot dipping zinc refers to the high quality steel into the zinc liquid pool of several thousand degrees, after soaking for a certain time, the zinc liquid will penetrate into the steel, so that it forms a special zinc steel alloy, hot dipping zinc material surface without any treatment in the field environment can reach 30 years without corrosion
Feature
Palisade fence with hot dipped galvanized or PVC coated types is widely used in factories and residences to protect people and properties' safe. Our palisade fencing systems are easily customizable to meet a variety of needs across a wide range of sectors. What’s more, palisade fencing can be combined with products to create the ultimate in protection for facilities requiring anti-ram and anti-vehicle capabilities.
Application
The specific products used in building guardrail are mainly: balcony guardrail, protective window, stair handrail, fence, garden fence, louver, air conditioning fence, road guardrail. Industrial fences (such as factory area fences, commercial site fences), agricultural fences (such as field fences, livestock fences), civil fences (such as building top fences, fence walls, etc.), fences for public facilities (such as road barriers) and so on. It is widely used.
Packing & Delivery
Company Profile
Yuanmai Hardware & Wire Mesh Products Co., Ltd. is a professional manufacturer of wire mesh fences, Our products include chainlink fences, farm fences, SNS protective mesh fences, framework fences, temporary fences, 358 High Security Fences, curvy welded mesh fences, prison fences, airport fences, ornamental fences, iron fences, palisade fences, double loop fences and Euro fences.
Yuanmai also supplies Hesco Bastions, reinforcing mesh, gabions, store cages and decorative wire mesh. Our factory located in Anping County, which is called "the Native land of Wire Mesh" in China.
Yuanmai also supplies Hesco Bastions, reinforcing mesh, gabions, store cages and decorative wire mesh. Our factory located in Anping County, which is called "the Native land of Wire Mesh" in China.
