MIL1 5442 R Barriers Container 54''X42'' barrier wall for defend damage metal mesh container

Price Negotiable

Price: $27 -$68/ Piece

MOQ: 1000pcs

Delivery Time: <20 work days

Brand: Yuanmai

Product Description

Products Description

Explosion wall, also known as blast resistant wall, has the ability to resist explosion shock wave, can limit the destruction of the explosion in a certain range of walls. Compared with reinforced concrete explosion-proof wall, it has the advantages of light weight, easy loading, easy unloading and recycling.

Product Paramenters

Defensive Barriers
PRODUCT	HEIGHT	WIDTH	LENGTH
MIL1 5442	54’’(1.37M)	42’’(1.06M)	32’9’’(10M)
MIL2 2424	24’’ (0.61M)	24’’(0.61M)	4’(1.22M)
MIL3 3939	39’’(1.00M)	39’’(1.00M)	32’.9’’(10M)
MIL4 3960	39’’(1.00M)	60’’(1.52M)	32’.9’’(10M)
MIL5 2424	24’’(0.61M)	24’’(0.61M)	10’(3.05M)
MIL6 6624	66’’(1.68M)	24’’(0.61M)	10’(3.05M)
MIL7 8784	87’’(2.21M)	84’’(2.13M)	91’(27.74M)
MIL8 5448	54’’(1.37M)	48’’(1.22M)	32’.9’’(10M)
MIL9 3930	39’’(1.00M)	30’’(0.76M)	30’’(9.14M)
MIL10 8760	87’’(2.21M)	60’’(1.52M)	100’(32.50M)
MIL11 4812	48’’(1.22M)	12’’(0.30M)	4’(1.22M)
MIL12 8442	84’’(2.13M)	42’’(1.06M)	108’(33M)
MIL19 10842	108’’(2.74M)	42’’(1.06M)	10’5’’(3.18M)

Exhibition

Detail

Reinforced concrete explosion-proof wall, steel explosion-proof wall, section steel explosion-proof wall, brick explosion-proof wall, flame retardant explosion-proof wall, special riot wall. The reinforcement crossing of reinforced concrete explosion-proof wall is firmly bound, and the wall thickness is usually 30 ~ 40cm; The depth of the thickened wall foundation should be greater than 1m. The explosion wall shall be able to withstand the impact pressure of 3MPa. Explosion-proof walls or other barrier facilities shall be installed between devices with explosive hazards and those without, as well as around devices with greater hazards.

Feature

Structural reinforcement: The horizontal reinforcement of 3 φ6-10 pass lengths is configured every 500mm along the height of the wall. The two ends of the horizontal reinforcement should be tied or welded with the buried reinforcement of the reinforced concrete frame or bracket column. When the length and height of the brick wall are greater than 6m, reinforced concrete intermediate columns and beams should be set up, and reinforced according to the structure. The strength grade of concrete shall not be lower than C15, and its end shall be connected with the roof beam, frame and bracket column; The thickness of reinforced concrete explosion-proof wall shall not be less than 180mm, and the strength grade of concrete shall not be less than C20. The section area of reinforcement shall be determined by structural calculation; No holes should be left in the explosion wall. When the process pipeline, cable, etc. must be passed through, the hole should not be greater than Φ200mm, the hole perimeter should be configured with reinforcement reinforcement, the hole should be filled with dense.
