4023 RRGBW Constant 24V 80W Tunable COB LED Adjustable CCT for Stage Light Performance lights Aquarium lights, swimming pool lights, ambient lights
Price:
5
MOQ:
1
Delivery Time:
Negotiable
Brand:
HYZM
Product Description
4023 RRGBW Constant 24V 80W Tunable COB LED Adjustable CCT
Professional COB LED chip designed for stage lighting, aquarium lights, swimming pool lights, and ambient lighting applications with tunable color temperature control.
4023 RRGBW Constant 24V 80W Tunable COB LEDp Overview
High-performance RRGBW COB LED chip offering versatile color mixing capabilities and pure white light output.
RGB vs RGBW vs RGBCW/WW Comparison
RGB LED Chips: Three-channel LED chips for custom color mixing. While white light can be achieved by mixing colors equally, this can result in discoloration and inconsistent results.
RGBW LED Chips: Feature an additional pure white channel for clean, consistent white light output with a single color temperature.
RGBCW/WW LED Chips: Include two white channels allowing adjustable color temperature between warm and cool white tones.
Red+Deep Red+Blue+Green+Cool White: new design this time. Add 660nm and the spectrum has been enriched, resulting in more vibrant colors.
4023 RRGBW Constant 24V 80W Tunable COB LED Features
- Dimensions: 40.0mm × 40.0mm × 1.2mm
- Wide viewing angle: 120°
- RoHS compliant
- Sulfation corrosion resistance
- Manual soldering compatible
Package Dimensions
Packaging: 49 PCS/Tray | 10 Trays/ESD Shielding Bag: 490 pcs
Electrical & Optical Characteristics (Ta=25℃)
| Type | Symbol | Test Condition | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|
| WaveLength(B) | λd | IF=750mA | 460 | -- | 470 | nm |
| WaveLength(R) | λd | IF=750mA | 620/660 | -- | 630/670 | nm |
| WaveLength(G) | λd | IF=750mA | 520 | -- | 530 | nm |
| Correlated Colour Temperature | CCT | IF=750mA | 8000 | 10000 | k | |
| Luminous Flux(B) | φv | IF=750mA | 100 | 150 | LM | |
| Luminous Flux(R) | φv | IF=750mA | 350 | 450 | LM | |
| Luminous Flux(G) | φv | IF=750mA | 400 | 500 | LM | |
| Luminous Flux(W) | φv | IF=750mA | 4000 | 5500 | LM | |
| Forward Voltage(B) | VF | IF=750mA | 24 | V | ||
| Forward Voltage(R) | VF | IF=750mA | 24 | V | ||
| Forward Voltage(G) | VF | IF=750mA | 24 | V | ||
| Forward Voltage(W) | VF | IF=750mA | 24 | V | ||
| Power(B) | PD | IF=750mA | 20 | W | ||
| Power(R) | PD | IF=750mA | 20 | W | ||
| Power(G) | PD | IF=750mA | 20 | W | ||
| Power(W) | PD | IF=750mA | 20 | W | ||
| Thermal resistance | Rth(j-s) | IF=750mA | -- | -- | 0.85 | ℃/W |
Absolute Maximum Ratings (Ta=25℃)
| Parameter | Symbol | Rating | Units |
|---|---|---|---|
| Junction temperature | Tj | 115 | ℃ |
| Solder temperature | Ts | 350 | ℃ |
| Operating Temperature | Topr | -40 ~ +85 | ℃ |
| Storage Temperature | Tstg | -40 ~ +100 | ℃ |
Applications
- Smart lighting systems
- Stage lighting
- Spot lights
- Down lights
- General lighting applications
Production Process
Frequently Asked Questions
Q1: Are you a factory or a trade company?
We are the manufacturer specializing in SMD and COB LED chips since 2013.
Q2: Can I get some samples for tests?
Yes, we can offer free samples for quality evaluation. Customers are responsible for shipping costs.
Q3: What about the lead time?
Samples: 3-5 working days | Mass orders: 7-25 working days
Q4: How many years of warranty do you offer? And how do you deal with LED working issues?
We offer a 3-year warranty by default, with longer terms negotiable. Contact us for any product issues during the warranty period.
Q5: Do you accept customized products?
Yes, we provide OEM and ODM services. Please contact us with your specific requirements for detailed consultation.
