Cylinder Mould

Our Stainless Steel Cylinder Mould have strong Casting Outside Spoke Space Plate which was molded for one time with solid and stable structure, steady operation and long life span. The external diameter of the cylinder mould work face is±2mm and wire face flatness degree is not more than 0.15mm. Wire face circular run-out is not more than 0.1mm and static balance equilibrium amount is not more than the 0.1% of the self weight. Cylinder Mould can be used for paper making, pulp washing and watermarks.

Material:

(1)Main shaft: Seamless steel tube, axle head 45# carbon steel, thermal refining

(2) Spoke: The Inside and outside spoke material is stainless steel or carbon iron. The inside spoke is inlayed stainless steel belt.

(3) Wire face: Stainless steel 304 sheet, space and bar

There are Decay resistance glass steel spacer sleeve between the two spokes.

(4) With bearing box and bearing block.
