Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
Price:
inquiry
MOQ:
1pc
Delivery Time:
5-8 working weeks
Brand:
ATMC
Product Description
KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
The KRAFT DRAFT DLA47816SM forming fabric features an innovative coarse-mesh, 8-over-16 shed double-layer construction. By integrating an additional cross-direction (CD) yarn, it delivers superior sheet support and formation stability. This weave maximizes drainage capacity, while its coarse, large-diameter wear-side weft yarns are engineered for exceptional abrasion resistance and extended operational life.
Key Features
-
Superior Sheet Support & Drainage: Coarse 8-shed paper side structure uniquely combines high fiber support with very high drainage capacity.
-
High Top Surface Open Area: The specific weave maximizes open area on the sheet side, directly contributing to rapid and efficient dewatering.
Product Parameters
| Product Name | Forming Fabric KRAFT DLA47816SM |
|---|---|
| Material | Polyester monofilament |
| Function | Paper Machine |
| Application | Light GSM Kraft Paper, Wrapping Paper, etc. |
| Technical | 1/1.5/2/2.5/3 layers forming fabric |
| Width | Customized |
| Weight | Customized |
| Fabric Color | Customized |
Product Images
Application
Wrapping and Packing Papers, Board Grades.
