SSB Triple Layer Forming Fabric KRAFT SSB60210WM57-380CFM for Paper Making – Fine Sheet Side & Long Float Wear Side for High Drainage
KRAFT SSB60210WM57-380CFM adopts a two‑shed paper side combined with a ten‑shed wear side in an SSB triple layer configuration. The fine forming side delivers even profiles and consistent fiber support, which promotes uniform sheet formation. On the wear side, long floats are arranged with a 3:2 CD shute ratio between forming and wear layers. This ratio permits the use of medium and coarse CD yarns, enhancing wear resistance and operational stability. Dual MD thread systems contribute to high cross‑directional rigidity. The fabric’s open structure supports aggressive dewatering while allowing easy showering. This model provides a reliable balance of sheet support, drainage capacity, and wear life for modern paper machines.
Key Features
- Paper side adopts two‑shed design for enhanced sheet formation.
- Wear side features ten‑shed construction to maximize service life.
- Fine and even paper side promotes consistent profile uniformity.
Product Parameters
| Product Name | Forming Fabric KRAFT SSB60210WM |
|---|---|
| Material | Polyester monofilament |
| Function | Paper Machine |
| Application | Light GSM Kraft Paper, Wrapping Paper, etc. |
| Technical | SSB Triple Layer forming fabric |
| Width | Customized |
| Weight | Customized |
| Fabric Color | Customized |
Product Images
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
