SSB Triple Layer - SSB50210WM55-380CFM Forming Fabric for Paper Making – Fine Sheet Support & High Drainage Capacity with Long Wear Side Float
Price:
inquiry
MOQ:
1pc
Delivery Time:
5-8 working weeks
Brand:
ATMC
Product Description
SSB Triple Layer - SSB50210WM55-380CFM Forming Fabric for Paper Making – Fine Sheet Support & High Drainage Capacity with Long Wear Side Float
KRAFT SSB50210WM is a standard SSB triple layer forming fabric designed with a two‑shed paper side and a ten‑shed wear side. The fine sheet forming side ensures even profiles and excellent fiber support for uniform paper formation. The open, long‑float wear side, combined with a 3:2 forming‑to‑wear side CD shute ratio, allows the use of medium to coarse CD yarns on the wear side. This construction significantly improves fabric life and provides outstanding stability via two MD thread systems. The open structure promotes high dewatering capacity and easy showering, making this fabric ideal for demanding paper machine positions.
Key Features
- Two-shed design on paper side for fine sheet support.
- Ten-shed construction on wear side for extended fabric life.
- Even and fine paper side ensures uniform sheet profiles.
Product Parameters
| Product Name | Forming Fabric KRAFT SSB50210WM |
|---|---|
| Material | Polyester monofilament |
| Function | Paper Machine |
| Application | Light GSM Kraft Paper, Wrapping Paper, etc. |
| Technical | SSB Triple Layer forming fabric |
| Width | Customized |
| Weight | Customized |
| Fabric Color | Customized |
Product Images
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
