SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
The KRAFT SSB50210WC48 is a triple layer forming cloth that combines a two‑shed paper side with a ten‑shed wear side for superior sheet support and drainage. The fine mesh on the paper side promotes uniform formation, while the wear side features long floats and a 3:2 CD shute ratio (forming side to wear side). This arrangement permits the use of medium and coarse CD yarns on the wear side, boosting durability and stability. Two MD thread systems provide excellent cross‑directional stability, reducing fabric distortion. The open weave structure not only enables high dewatering rates but also allows easy showering, making this fabric a reliable choice for paper machines requiring extended running time.
- Medium CD yarns used on wear side for balanced durability.
- Long float design on wear side provides exceptional wear potential.
- Good fiber support enables uniform paper formation.
| Product Name | Forming Fabric KRAFT SSB50210WC |
|---|---|
| Material | Polyester monofilament |
| Function | Paper Machine |
| Application | Light GSM Kraft Paper, Wrapping Paper, etc. |
| Technical | SSB Triple Layer forming fabric |
| Width | Customized |
| Weight | Customized |
| Fabric Color | Customized |
