0.5mm Thickness 304 Metal Pall Ring Distillation Tower Packing 25mm
Price:
Negociation
MOQ:
1pc
Delivery Time:
5-10 days
Brand:
Yuanqiao
Product Description
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
25mm 304 Distillation Tower Pall Ring Packing 0.5 Mm Thickness
Description| Product Name: | Metal Pall Ring | Size: | 1 In / 25 Mm |
|---|---|---|---|
| Material Certificate: | Yes | Wall Thickness: | 0.5 Mm |
| Data Sheet: | Available | OEM: | Yes |
| Material: | SS304 | Application: | Distillation Tower Packing |
| Sample: | Free Sample | Warranty: | Lifetime Online Service |
| High Light: |
25mm metal pall ring,25mm pall ring packing,distillation tower pall ring packing |
||
25 Mm 304 Distillation Tower 0.5 Mm Thickness Metal Pall Ring
1. Metal Pall Ring Basic Info:
Metal pall rings have more than 50% higher capacity than raschig ring. The pressure drop is only half of the raschig ring. The relative efficiency is about 30% higher than that of raschig ring.
2. 25 mm Metal Pall Ring Specification:
| 25mm Pall Rings | ||
| Free Space (%) | 94 |  |
| Specific Surface Area (m2/m3) 209 | ||
| No. Per Unit Volume (m3 ) | 49,500 | |
| Packing Factor (m-1) | 176 | |
|
Specific Weight (kg/m3) 322 – 644 Stainless Steel |
||
| Dimensions (mm) | 25 x 25 | |
| Thickness (mm) | 0.4 – 0.8 | |
3. Metal Pall Ring is a new type of filler improved on Raschig ring.
Compared with the later, pall ring has improved the liquid distribution of filler layer greatly, with open windows on ring sidewall. Therefore it has productivity, low resistance, operating flexible and higher efficiency. Pall ring is widely applied to industry. It is still one of major annular fillers that has been adopted.
4. Metal Pall Ring Features:
Easily wettable
High resistance to fouling
High temperature endurable
High temperature applications
HIGH MECHANICAL STRENGTH
High capacity with low pressure drop
Mechanically robust, lesser probability of breakage
Good liquid/gas distribution and high mass transfer efficiency
