Dn50 Random Tower Packing Raschig Rings SS304 For Chemical Industry
Price:
Negociation
MOQ:
1pc
Delivery Time:
5-10 days
Brand:
Yuanqiao
Product Description
Dn50 Tower Random Ss304 Packing Pall Ring For Chemical Industry
Dn50 Tower Random Ss304 Packing Pall Ring For Chemical Industry
Description| Items: | Metal Pall Ring | Material: | SS304, SS316L SS316, Other |
|---|---|---|---|
| Size: | 9mm-76mm ETC | Wall Thickness: | 0.3-1.2mm |
| Model Number: | HL20211012-02 | Usage: | Absorption ,Chemical Engineering ETC |
| Material Certificate: | Yes | Data Sheet: | Available |
| OEM: | Yes | Equal Inch Type: | 1in, 2in, 3in, 3/8in, 5/8in, 1 1/2inch Other |
| High Light: |
ss304 packing pall ring,dn50 packing pall ring,chemical industry 50 mm pall ring |
||
SS304 DN50 Tower Random Packing For Chemical Industry Metal Pall Ring
Product Introduction
1. The pall ring is an improvement of the raschig ring.
2. The difference for the Pall Ring is the addition of two rows of punched and formed fingers.
3. This adjustment provides a significant performance increase: the capacity and efficiency is improved and the pressure drop is reduced.
Technical Data of metal pall rings:
| Nominal size | 16 mm pall ring |
| Thickness | 0,3 mm |
| Weight | 340 kg/m³ |
| Surface area | 360 m²/m³ |
| Void fraction | 95 % |
| Material | stainless steel |
| Available materials | carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request |
| Nominal size | 25 mm pall ring |
| Thickness | 0,5 mm |
| Weight | 393 kg/m³ |
| Surface area | 215 m²/m³ |
| Void fraction | 95 % |
| Material | stainless steel |
| Available materials | carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request |
| Nominal size | 38 mm pall ring |
| Thickness | 0,5 mm |
| Weight | 285 kg/m³ |
| Surface area | 145 m²/m³ |
| Void fraction | 96 % |
| Material | stainless steel |
| Available materials | carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request |
| Nominal size | 50 mm pall ring |
| Thickness | 0,5 mm |
| Weight | 207 kg/m³ |
| Surface area | 112 m²/m³ |
| Void fraction | 97 % |
| Material | stainless steel |
| Available materials | carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request |
| Nominal size | 76 mm pall ring |
| Thickness | 0,7 mm |
| Weight | 109 kg/m³ |
| Surface area | 78 m²/m³ |
| Void fraction | 98 % |
| Material | stainless steel |
| Available materials | carbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request |
Material
Metal Pall Ring, Stainless steel Pall rings, Packing Pall Ring are available in a wide range of materials such as stainless steel ,carbon steel ,aluminum, bronze,304L,316L,and other alloy etc.
Applications of metal pall rings
| 1 | Degassing |
| 2 | Gas washing |
| 3 | Steam stripping |
| 4 | Air pollution control scrubbers |
| 5 | H2S, NH3 & SO2 absorption and stripping |
