316L Steel Grids And PTFE Mist Eliminator Demister Mat ISO9001-2015
316L Steel Grids And PTFE Mesh Pad Demister ISO9001-2015 Certification
316L Steel Grids And PTFE Mesh Pad Demister ISO9001-2015 Certification
PTFE is usually considered the king of the plastic materials. It has perfect resistance to acid and other corrossive solutions. And It has good performance with a relatively high temperature. The working temperature of PTFE material can be as high as 250 ℃. PTFE mesh pad is made of knitted PTFE wire mesh tube. If grids are needed, both PTFE and SS316L materials are available with us. Like in this case, if SS316L steel flat bar grids can withstand this corrosive working condition, no doubt it is a good choice to save some cost. Because PTFE material is much more expensive than SS316L.
PTFE + 316L demister mist eliminator in this case
| Item | Value | Unit |
| Material | PTFE+SS316L | / |
| Shape & Size | Φ2200 | mm |
| Mesh Thickness | 100 | mm |
| Demsiter Height | 150 | mm |
| Wire Diameter | 0.3 | mm |
| Effect Area | 3.8 | m2 |
| Sections | 8 | / |
| Grids | 25*3 steel flat bar | mm |
The demister mist eliminator is installed above the surface of the liquid with some distance. From one hand it allows some space for the natural disengagement of the coarsest natural particles. From the other hand, it ensures that the gas/ vapour flow is uniform over the whole area of the mist eliminator
The gas / vapor containing droplets passes into demister mist eliminator at a predetermined velocity. It easily finds open path through the mesh but the droplets and mist impinge on the filaments of mesh where they coalesce and eventually grow to such a size to overcome surface tension of liquid and force of gravity. Then the liquid droplets so formed fall down. And the mist free gas / vapour passes through the mesh demister pad.
