Product Description
- Protection against Environmental Factors: IP65 IP4X Protection ensures that the switchgear is protected against dust, water, and other environmental factors, making it suitable for use in harsh outdoor environments.
- Drawout Design: The switchgear features a drawout design, which allows for easy maintenance and repair of the equipment without the need for extensive downtime.
- High Voltage and Low Voltage Capabilities: This type of switchgear is capable of handling both high voltage and low voltage applications, making it a versatile solution for a range of electrical systems.
- Advanced Control Systems: The switchgear is equipped with advanced control systems, which allow for remote monitoring and management of the system. This includes real-time monitoring of equipment status, as well as the ability to remotely control power distribution and other functions.
- Customizable Options: There are a range of options available for this type of switchgear, including different voltage levels, busbar configurations, and protection options, allowing for a customized solution that meets specific user requirements.
- Energy Efficiency: The switchgear is designed to improve energy efficiency and reduce energy consumption. It can regulate voltage and power factor to minimize energy losses, and can also be integrated with renewable energy sources such as solar and wind power.
Overall, IP65 IP4X Protection Outdoor Type Drawout High Tension Low Voltage Switchgear offers a range of features and benefits that make it a reliable and efficient solution for outdoor electrical distribution. Its drawout design, customizable options, and advanced control systems make it well-suited for a range of applications, including industrial plants, commercial buildings, and renewable energy systems.
Specification
| Rated Insulation voltage | 690V (1000)V |
| Rated working voltage | 380V, 400V, 690V |
| Maximum working current of main bus | 6300A |
| Rated withstand current of main busbar | 100kA/1s |
| Main busbar rated peak withstand current | 220kA/0.1s |
| Maximum operating current of branch distribution bus (vertical bus) | 2000A |
| Standard type | 105kA(Max)/0.1s |
| Reinforced type | 176kA(Max)/0.1s |
| Protection level | IP4X, IP41,IP65 |
Production Facilities
Company Profile
1.Chongqing Bosun Electrical Co., Ltd. was established in 1996, located in Banan District Chongqing China, with convenient transportation, covers an area of 8,000 square meters.
2.Devoted in the research and development, manufacturing, installation, and sales of complete sets of high and low voltage switchgear and control equipment from 40.5kV to 0.22kV.
3.more than 20 CCC/CQC certificates, meet the requirements of the highest protection level of IP65 and altitude environment of 4500 meters, get the GB/T19001:2016 /ISO9001:2015 quality management system certification,
4.A complete product development department, design team.
5.Various kinds of product construction and manufacturing design by using specialized computer mechanical and electrical CAD design software systems.
6.Complete surveillance, measuring, and testing equipment to ensure the high products quality.
7.Complete production line including CNC processing equipment, welding equipment, and hoisting equipment required for cabinet production, busbar bending equipment, tinning equipment, electric tools, and other assembly production equipment required for complete assembly production.
8.More than 10 product invention patents and utility model patents.
9.Excellent service based on the motto "Quality First, Customer Foremost, Survival Through Quality, Development Through Service, Continuous Improvement."
