IEC Pad Mounted MCC Low and Medium Voltage Switchgear 690V
IEC Pad mounted MCC Low and Medium Voltage Switchgear for Commercial Buildings
Product Description
- Power distribution and control: Low-voltage switchgear, as an important component of the power system, can be used for power distribution and control to ensure the safe and stable operation of the power system. In large buildings such as real estate and commercial buildings, low-voltage switchgear can distribute power to different areas to meet different power needs.
- Lighting control: Low-voltage switchgear can control the switch and dimming of the lighting system, achieve effective control of lighting equipment, improve lighting efficiency, and save energy.
- Air conditioning control: Low-voltage switchgear can control the switch and temperature of the air conditioning system, achieve effective control of air conditioning equipment, improve air conditioning efficiency, and save energy.
- Safety monitoring: Low-voltage switchgear can be integrated with the safety monitoring system to achieve remote monitoring and alarm of electrical equipment, improve safety and reliability.
In summary, the role of low-voltage switchgear in fields such as real estate and commercial buildings is very important. It can improve the safety, stability, and efficiency of the power system, and can also achieve effective control and energy saving of lighting, air conditioning, and other equipment.
Specification
| Rated Insulation voltage | 690V (1000)V |
| Rated working voltage | 380V, 400V, 690V |
| Maximum working current of main bus | 6300A |
| Rated withstand current of main busbar | 100kA/1s |
| Main busbar rated peak withstand current | 220kA/0.1s |
| Maximum operating current of branch distribution bus (vertical bus) | 2000A |
| Standard type | 105kA(Max)/0.1s |
| Reinforced type | 176kA(Max)/0.1s |
| Protection level | IP4X, IP41,IP65 |
Material
1.The cabinet door adopts a double beveled edge process, which increases the structural strength of the same material by 50%.
2.The installation holes are all made using a multi-layer stamping and stretching process, which reduces the sliding wire situation by more than 80%.
3.The inlet and outlet holes adopt a composite structure of knockdown holes and square holes, which can be flexibly selected during on-site installation.
4.The box adopts a double folding process, which increases the structural strength of the same material by 50%.
5.The control circuit adopts a composite design of debugging mode and fire protection mode, greatly reducing the burning of fan and water pump equipment designed for fire protection during debugging.
Marketing
Our cooperative partners come from 6 continents and over 50 countries.
Team Show
1.Professional team
2.Comprehensive services
3.Strict quality control
4.Comprehensive inspection
5.Responsibility guarantee
