7.4 Meters Cable Column Mounted 11kw Home Type 1 EV Charger With RFID Card

Price Negotiable
Price: negotiated
MOQ: 1 piece
Delivery Time: 5-15 days
Brand: RC
Product Description

7.4 Meters Cable Column Mounted 11kw Type 1 EV Charger With RFID Card



Product Description



1. 7.4 Meters Cable Column Mounted 11kw Type 1 EV Charger With RFID Card comes with a generous 7.4 meters cable length, providing flexibility and convenience for charging in various parking configurations.
2. With an impressive 11kw power output, this charger delivers fast and efficient charging for Type 1 electric vehicles, allowing for quicker turnaround times.
3. Designed specifically for Type 1 electric vehicles, this charger offers a reliable and user-friendly charging solution, ensuring compatibility and ease of use for owners of compatible vehicle models.



Specification



Product 7.4 Meters Cable Column Mounted 11kw Type 1 EV Charger With RFID Card
Model for 40A RC-EV-096KUS-01C RC-EV-096KUS-01C RC-EV-7KEU-01CB
Input / Output Voltage AC 110~240V/ Single phase Input / Output Current 8, 10, 12, 14, 16A, 20, 24, 28, 32A, 36A, 40A adjustable
Max Output Power 9.6KW Frequency 50/60Hz
Input Cable NEMA 14-50P/ 1M, hard-wired Output plug SAE J1772 (Type1)
Output Cable 7.4M Withstand Voltage 2000V
Work Altitude <2000M Stand by <3W
Protection over voltage protection, over load protection, over-temp protection, under voltage protection, earth leakage protection, lightning protection, short circuit protection
Touch Button Yes LCD Screen 3.5"
Current Adjustment Yes Timing / Appointment Yes
Bluetooth APP cherging Yes(Optional) WiFi APP cherging Yes(Optional)
RFID Yes Certification

FCC, ETL, RoHS

Model for 48A RC-EV-115KUS-01C RC-EV-115KUS-01C
Input / Output Voltage AC 110~240V/ Single phase Input / Output Current 8, 10, 12, 14, 16A, 20, 24, 28, 32A, 36A, 40A adjustable
Max Output Power 11.52KW Frequency 50/60Hz
Input Cable NEMA 14-50P/ 1M, hard-wired Output plug SAE J1772 (Type1)
Output Cable 7.4M Withstand Voltage 2000V
Work Altitude <2000M Stand by <3W
Protection over voltage protection, over load protection, over-temp protection, under voltage protection, earth leakage protection, lightning protection, short circuit protection
Touch Button Yes LCD Screen 3.5"
Current Adjustment Yes Timing / Appointment Yes
Bluetooth APP cherging Yes(Optional) WiFi APP cherging Yes(Optional)
RFID Yes Certification FCC, ETL, RoHS

Factory Introduction



We are a company specializing in EV charging stations, offering OEM and ODM services. With 8 years of experience in the field, we are committed to providing our customers with high-quality and reliable charging station solutions.
Our team possesses extensive technical expertise and industry knowledge, enabling us to customize charging station products based on our customers' specific requirements while ensuring compliance with the highest standards and regulations.
From design to manufacturing and after-sales service, our primary focus is customer satisfaction, and we actively contribute to the advancement of electric vehicle charging infrastructure.
If you are seeking an experienced and trustworthy partner for customized solutions in the EV charging domain, we are ready to deliver excellent products and professional support.



Features



1. Universal compatibility - support major charging standards like CCS, CHAdeMO, GB/T to serve different EVs.

2. High-power DC fast charging - enable ultra-fast charging to minimize downtime.

3. Smart networking - allow remote monitoring, access control, payment integration for operators.

4. Customizable - tailored charging solutions designed to customer specifications.

5. Reliable - rigorously tested to ensure safety and reliable performance.

6. Intelligent charging - optimize charging through smart algorithms and V2I connectivity.

7. User-friendly - interactive interfaces with LED/LCD displays, voice guidance.

8. Eco-conscious - integrate renewable energy sources for low-carbon charging.

9. End-to-end service - from design, manufacturing to installation and maintenance.
