China Cylinder Gas Inflammable Compressed High Purity Germane Geh4 Gas

Price Negotiable
Price: US $100/kg
MOQ: 1kg
Delivery Time: 15 days
Brand: CMC
Product Description

Inflammable Compressed Germane Geh4 Gas Cylinder Tank

Germane gas (GeH4) is a colorless, flammable, and highly toxic gas. It belongs to the group of compounds known as hydrides, which are formed by combining hydrogen with various elements. Here are some key points about germane gas:

  1. Chemical Composition: Germane gas is composed of one germanium atom bonded to four hydrogen atoms (GeH4).

  2. Properties: Germane gas possesses several important properties:

    • Toxicity: Germane gas is highly toxic and poses significant health hazards. Inhalation of germane gas can cause severe health effects, including respiratory distress, eye and skin irritation, and damage to the central nervous system.

    • Flammability: Germane gas is flammable and can form explosive mixtures with air. It has a wide flammable range and can ignite at relatively low temperatures or when exposed to a flame or spark.

    • Stability: Germane gas is unstable and can decompose or react with other substances under certain conditions.

  3. Production: Germane gas can be produced by various methods, including:

    • Direct Combination: Germane gas can be produced by combining germanium tetrachloride (GeCl4) with hydrogen gas (H2) in the presence of a reducing agent.

    • Decomposition: Germane gas can also be generated by the decomposition of certain germanium hydride compounds through thermal or chemical reactions.

  4. Uses: Germane gas has limited practical applications due to its toxicity and instability. Some notable uses include:

    • Semiconductor Manufacturing: Germane gas is used in the production of semiconductors and thin-film devices. It is employed as a dopant gas to introduce germanium atoms into silicon-based materials during the fabrication process.

    • Research and Laboratory Applications: Germane gas is sometimes used in research laboratories for specific experiments or as a precursor for the synthesis of certain germanium-containing compounds.

  5. Safety Considerations: Due to its toxicity and flammability, germane gas requires careful handling and strict safety precautions. Proper ventilation, personal protective equipment, and adherence to safety guidelines are essential when working with germane gas. Additionally, storage and transportation should be done in compliance with applicable regulations.

It is important to note that germane gas should only be handled by trained professionals in properly equipped facilities due to its hazardous nature.



Model NO. GeH4 Constituent Germane 99.999%
Grade Standard Electronic Grade Chemical Property Inflammable Gas
Trademark CMC Transport Package 44L
Specification 99.999 Origin China




Germane - ( GeH4 )
Description
Germane is a flammable , colorless gas with characteristic pungent ,nauseating odor .Its boiling point is - 90°C.  It is unstable and can decompose explosively when heated to greater than 330°C.

Specifications
Purity , % 99.999
Oxygen + Argon  ≤0.5 ppmv
Nitrogen ≤2.0  ppmv
Carbon Dioxide ≤2.0 ppmv
Carbon Monoxide ≤1.0 ppmv
Methane  ≤1.0 ppmv
Water  ≤1.0 ppmv
Chlorogermanes ≤5.0 ppmv
Digermane* ≤20.0 ppmv
Germoxanes ≤5.0 ppmv
Hydrogen* ≤50.0 ppmv
Trigermane  ≤1.0  ppmv

Ship
DOT Shipping Name  Germane
DOT Classification 2.3
DOT Label  Toxic Gas, Flammable Gas
UN Number  UN2192
CAS No. 7782-65-2
CGA/DISS/JIS 350/632/W22-14L
Shipped as  Compressed Gas

Technical Information
Cylinder State @ 21.1°C  Gas
Flammable Limits In Air  0.5-100%
Auto Ignition Temperature (°C ) 54.4
Molecular Weight (g/mol) 76.62
Specific gravity (air =1) 2.65
Critical Temperature ( °C ) 34.8
Critical Pressure ( psig )

Applications
Used for the deposition of epitaxial and amorphous silicon - germanium alloys , and as a component for
PECVD of ( Si, Ge )O2 films with controllable refractive index for photonic .

Detailed Photos


Wholesale 99.999% High Quality Germane Gas Geh4 Gas
Wholesale 99.999% High Quality Germane Gas Geh4 Gas


Company Profile

Wholesale 99.999% High Quality Germane Gas Geh4 Gas

Shanghai Kemike Chemical Co., Ltd is staffed by trained personnel, combine many years experience in Gas industry .We supply cylinder gas, electronic gas, etc ., and the gas holder, panel, valves and fittings and other equipment, parts and engineering services to our customers in China and worldwide; The products are involved in various industrial fields, such as semiconductor chip, solar cell, LED, TFT-LCD, optical fiber, glass, laser, medicine , etc., Our mission is to partner with our global customers to provide support, solutions and quality products that are innovative,reliable, and safe.
Our products mainly include: H2, O2, N2, Ar, CO2, propane, acetylene, helium, laser mixed gas,  SiH4, Sih2cl2, SiHCL3, SiCL4, NH3, CF4, NF3, SF6, HCL, N2O, doping mixed gas (TMB, PH3, B2H6) and other electronic gases.

Wholesale 99.999% High Quality Germane Gas Geh4 Gas
Wholesale 99.999% High Quality Germane Gas Geh4 Gas
