Automatic hydraulic hot press machine board veneer hot press block board hot press machine
Price:
$13,400.00/sets 1-4 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
ZD
Product Description
Product Description
Product Advantage
1.The main hydraulic parts are imported,adjustable pressure.
2.The heating platen is made of high quality solid carbon steel with high precision, high strength.
3.Heating system,with the meticulous segmented design,which can lower energy consumption, uniform heat conduction, adjust the temperature.
4. The Cylinder is made by precision CNC machine and adopts imported oil seal, no oil leakage.
4. The Cylinder is made by precision CNC machine and adopts imported oil seal, no oil leakage.
Specification
Model | ZD214/160(1)H |
Total pressure(KN) | 1600KN |
Platen No&size(mm) | 3000×1500x42mm |
Opening(mm) | 80-200mm |
Working layer Numbers | 1 |
Cylinder No&Diameter(mm) | 8* Φ100mm |
Heating Method | Electric heated with conduction oil |
Hot platen open way | Automatically |
Closing speed(mm/s) | 40mm/s |
PRODUCT DETAILS
The hydraulic system of this machine uses Taiwan Qingtian hydraulic components and high and low pressure oil pumps, equipped with a three-blade 5.5kw oil pump special motor, and the ascent speed is about 30mm/S
The cylinder is a solid plunger rod that is hard chrome-plated, with imported sealing ring inside, with a diameter of 100mm and an effective stroke of 300mm.
The hot plate is a solid drilled plate, and the oil circuit layout is reasonable and even, which greatly guarantees the heating speed and uniform temperature of the hot plate.
Base is type H steel.Ensure stable operation.
COMPANY PROFILE
Qingdao Zhongding Machinery Co.,Ltd
Qingdao Zhongding Machinery Co.,Ltd, is a leading company which is specializing in manufacturing and exporting woodworking machines. Our company has professional technology, full range of testing lines and pipelining, and four professional production lines of woodworking machine.
Our main products include Precise panel saw, Edge banding machine, Multiple Drilling machine, Hot press machine, cold press machine, which had been exported to a lots of countries and regions, such as European, Southeast Asia, North America, Russia, Mid East and Australia,etc.
Our main products include Precise panel saw, Edge banding machine, Multiple Drilling machine, Hot press machine, cold press machine, which had been exported to a lots of countries and regions, such as European, Southeast Asia, North America, Russia, Mid East and Australia,etc.
FACTORY PICTURES
RELATED PRODUCTS
PACKAGE AND DELIVERY
Ship terms:
1. We can arrange the shipping by sea, air, truck and train based on your requirements, but kindly remind the refrigerant gas isn't allowed by air ,so you must filling them when machine arrive if you choose the air ship.
2. FOB, CNF, CIF can be accepted.
3. Any port of CHINA we can sent ,if you have other goods will packaged in one container ,we would like to arrange that for you.
2. FOB, CNF, CIF can be accepted.
3. Any port of CHINA we can sent ,if you have other goods will packaged in one container ,we would like to arrange that for you.
FAQ
Q:Are you a manufacturer?
Yes, 15 years manufacturing experience.
Q: Do you offer installation?
Our machines are almost assembled before loading in container. It is very easy for installation in your workshop. Video guidance and English manual can be provided freely. Engineers can be sent to service in site if the buyer request.
Q:What is language of the operation system?
Any language as your request.
Any language as your request.
Q：Where can we get replacement parts? Most of the spare parts are ready in stock. They will be sent to the buyer directly from our warehouse with original prices.
Q：What technical support do you offer? 1. Technical support by phone, email or WhatsApp/Skype around the clock. 2. Friendly English version manual and operation video. 3. Engineer available to service machinery overseas.
Q：Can you customized the machine? Our machines can be customized made according to buyers’ request.
Q：What other machines do you offer? We provide one-stop shop service of woodworking machines for the buyers. Other kinds of woodworking machines, like Edge banding machine,Sanding machine, CNC router, Drilling machine, Saw machine can be provided as well.
