Supermicro Hyper SuperServer SYS-122HA-TN-LCC with Intel Xeon 6900 Series Processors 12 Hot-Swap NVMe Drive Bays and 1600W Redundant Titanium Power Supplies
Price:
Negotiable
MOQ:
1/set
Delivery Time:
2-3 work days
Brand:
Supermicro
Product Description
Supermicro Hyper SuperServer SYS-122HA-TN-LCC
Primary Applications
Artificial Intelligence (AI), Virtualization, High Performance Computing, Data Analytics
Key Features
- Dual Intel® Xeon® 6900-Series Processors with P-cores up to 500W with D2C liquid cooling
- Up to 24 DIMMs supporting up to 6TB 6400MT/s DDR5 RDIMM or 3TB 8800MT/s DDR5 MRDIMM
- 12 front hot-swap 2.5" NVMe drive bays
- 2 PCIe 5.0 x16 slots (full-height, 10.5" length)
- 1 AIOM/OCP 3.0 NIC slot for flexible networking options
- Redundant titanium level power supplies with options from 1600W to 2600W
- 1U Rackmount chassis with 30.66" (778.7mm) depth
Technical Specifications
| Form Factor | 1U Rackmount Enclosure: 437 x 43 x 778.7mm (17.2" x 1.7" x 30.66") Package: 672 x 224 x 1100mm (26.46" x 8.82" x 43.31") |
|---|---|
| Processor | Dual Socket BR (LGA-7529) Intel® Xeon® 6900 series processors with P-cores Up to 128C/256T; Up to 504MB Cache per CPU |
| System Memory | Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM Max Memory (1DPC): Up to 3TB 8800MT/s ECC DDR5 MRDIMM |
| Drive Bays Configuration | Default: Total 12 bays 12 front hot-swap 2.5" NVMe drive bays M.2: 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110) |
| Expansion Slots | Default 2 PCIe 5.0 x16 FH/10.5"L slots 1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible) |
| On-Board Devices | NVMe: NVMe; RAID 0/1/5/10 support (Intel® VROC RAID key required) Chipset: System on Chip Network Connectivity: Via AIOM |
| Power Supply | 2x 1600W Redundant (1 + 1) Titanium Level (96%) Hot-plug power supplies |
| Dimensions and Weight | Weight: Gross Weight: 41.4 lbs (18.8 kg) Net Weight: 19.2 lbs (8.7 kg) Available Color: Silver |
Product Images
