Supermicro Hyper SuperServer SYS-121C-TN2R with 5th Gen Intel® Xeon® 16 DIMM Slots and 8 Hot-Swap Drive Bays
Price:
Negotiable
MOQ:
1/set
Delivery Time:
2-3 work days
Brand:
Supermicro
Product Description
Supermicro Hyper SuperServer SYS-121C-TN2R
Key Applications
- Web Server
- Firewall Application
- Data Center Optimized
- Value IaaS
- Cloud Computing
- Compact Server
- DNS & Gateway Servers
- Content Delivery Network (CDN)
- Edge Nodes
Key Features
- Dual Socket E (LGA-4677) 5th and 4th Gen Intel® Xeon® Scalable processors
- 16 DIMMs supporting up to 4TB 3DS ECC DDR5-5600 RDIMM
- 2 PCIe 5.0 x16 FHHL expansion slots
- 2 PCIe 5.0 x4 NVMe M.2 slots
- Dual AIOM (OCP 3.0) slots with NCSI for networking
- Dedicated IPMI LAN port
- 8x 2.5" hot-swap SATA/SAS4 drive bays with 2x hybrid NVMe drive bays
- 1 VGA, 1 COM, and 2 USB 3.0 rear ports
Technical Specifications
| Form Factor | 1U Rackmount Enclosure: 437 x 43 x 597mm (17.2" x 1.7" x 23.5") Package: 605 x 197 x 822mm (23.8" x 7.8" x 32.4") |
|---|---|
| Processor | Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors Up to 36C/72T; Up to 82.5MB Cache per CPU |
| GPU | Max GPU Count: Up to 2 single-width GPUs Supported GPU: NVIDIA PCIe: L4, A2 Intel PCIe: Intel Data Center GPU Flex 140 |
| System Memory | Slot Count: 16 DIMM slots Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM |
| Drive Bays Configuration | Default: Total 8 bays 2 front hot-swap 2.5" NVMe/SAS/SATA drive bays 6 front hot-swap 2.5" SAS/SATA drive bays (NVMe/SAS/SATA support may require additional storage controller and/or cables) M.2: 2 M.2 PCIe 5.0 x4 NVMe slots (M-key 2280 default; VROC required for RAID) Peripheral Bays: 1 slim DVD bay (optional) |
| Expansion Slots | Default 2 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible) |
| On-Board Devices | SATA: SATA (6Gbps); RAID 0/1/5/10 support NVMe: NVMe; RAID 0/1/5/10 support (VROC HW key required) Chipset: Intel® C741 Network Connectivity: Via AIOM |
| Power Supply | 2x 860W Redundant (1 + 1) Titanium Level (96%) Hot-plug power supplies |
| Dimensions and Weight | Weight: Gross Weight: 40 lbs (18.1 kg) Net Weight: 25 lbs (11.3 kg) Available Color: Black front & silver body |
