Supermicro 1U Rackmount GPU Server ARS-111GL-DNHR-LCC with NVIDIA Grace Hopper Superchip 480GB ECC LPDDR5X Memory and 2x 2700W Redundant Titanium Power Supplies
Price:
Negotiable
MOQ:
1/set
Delivery Time:
2-3 work days
Brand:
Supermicro
Product Description
Supermicro GPU Server ARS-111GL-DNHR-LCC
Key Applications
High Performance Computing, AI/Deep Learning Training and Inference, Large Language Model (LLM) and Generative AI
Key Features
- Two nodes in a 1U form factor
- High density 1U 2-node GPU system with Integrated NVIDIA® H100 GPU (1 per Node)
- NVIDIA Grace Hopper™ Superchip (Grace CPU and H100 GPU)
- NVLink® Chip-2-Chip (C2C) high-bandwidth, low-latency interconnect between CPU and GPU at 900GB/s
- Up to 576GB of coherent memory per node including 480GB LPDDR5X and 96GB of HBM3 for LLM applications
- 2x PCIe 5.0 x16 slots per node supporting NVIDIA BlueField®-3 or ConnectX®-7
- 7 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control
- Supports two E1.S drives directly from the processor
Technical Specifications
| Form Factor | 1U Rackmount Enclosure: 440 x 44 x 940mm (17.33" x 1.75" x 37") Package: 1219 x 241 x 711mm (48" x 9.5" x 28") |
|---|---|
| Processor | NVIDIA 72-core NVIDIA Grace CPU on GH200 Grace Hopper™ Superchip |
| GPU | Max GPU Count: 1 onboard GPU Supported GPU: NVIDIA: H100 Tensor Core GPU on GH200 Grace Hopper™ Superchip CPU-GPU Interconnect: NVIDIA NVLink™-C2C GPU-GPU Interconnect: PCIe |
| System Memory | Slot Count: Onboard Memory Max Memory: Up to 480GB ECC LPDDR5X Additional GPU Memory: Up to 96GB ECC HBM3 |
| Drive Bays Configuration | Default: Total 4 bays 4 front fixed E1.S NVMe drive bays M.2: 2 M.2 NVMe slots (M-key) |
| Expansion Slots | Default 2 PCIe 5.0 x16 FHFL slots |
| On-Board Devices | System on Chip |
| System Cooling | Fans: Up to 7 Removable heavy-duty 4cm Fan(s) Liquid Cooling: Direct to Chip (D2C) Cold Plate (optional) |
| Power Supply | 2x 2700W Redundant Titanium Level (96%) power supplies |
| System BIOS | BIOS Type: AMI 64MB SPI Flash EEPROM |
| PC Health Monitoring | CPU: Monitors for CPU Cores, Chipset Voltages, Memory FAN: Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature: Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Dimensions and Weight | Weight: Gross Weight: 65.5 lbs (29.7 kg) Net Weight: 48.5 lbs (22 kg) Available Color: Silver |
| Operating Environment | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
