Supermicro 1U Rackmount GPU Server ARS-111GL-DSHR-LCC with NVIDIA Grace Hopper Superchip 480GB ECC LPDDR5X Memory and 2x 2700W Redundant Titanium Power Supplies
Price:
Negotiable
MOQ:
1/set
Delivery Time:
2-3 work days
Brand:
Supermicro
Product Description
Supermicro GPU Server ARS-111GL-DSHR-LCC
Key Applications
High Performance Computing, AI/Deep Learning Training and Inference, Large Language Model (LLM) and Generative AI
Key Features
- Two nodes in a 1U form factor - each node supports up to eight E1.S drives with NVIDIA's BlueField®-3 in Storage Configuration Mode
- High density 1U 2-node GPU system with Integrated NVIDIA® H100 GPU
- NVIDIA Grace Hopper™ Superchip (Grace CPU and H100 GPU), up to 72 cores per node (Liquid-Cooled)
- NVLink® Chip-2-Chip (C2C) high-bandwidth, low-latency interconnect between CPU and GPU at 900GB/s
- Up to 576GB of coherent memory per node including 480GB LPDDR5X (CPU) and 96GB of HBM3 (GPU) for LLM applications
- 2 PCIe 5.0 x16 slots per node (1 PCIe FHFL slot dedicated to BlueField-3 and 1 PCIe LP)
- Supports up to eight hot-swap E1.S drives bays (four per node)
- 7 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control
Product Specifications
| Form Factor | 1U Rackmount Enclosure: 438.4 x 43.6 x 900mm (17.26" x 1.7" x 35.4") Package: 695 x 230 x 1170mm (27.36" x 9.05" x 46.06") |
|---|---|
| Processor | NVIDIA 72-core NVIDIA Grace CPU on GH200 Grace Hopper™ Superchip |
| GPU | Max GPU Count: Up to 1 onboard GPU Supported GPU: NVIDIA: H100 Tensor Core GPU on GH200 Grace Hopper™ Superchip GPU-GPU Interconnect: PCIe |
| System Memory | Slot Count: Onboard Memory Max Memory: Up to 480GB ECC LPDDR5X Additional GPU Memory: Up to 96GB ECC HBM3 |
| Drive Bays Configuration | Default: Total 4 bays 4 front hot-swap E1.S NVMe drive bays M.2: 2 M.2 NVMe slots (M-key) |
| Expansion Slots | Default 1 PCIe 5.0 x16 FHFL slot 1 PCIe 5.0 x16 LP slot |
| On-Board Devices | System on Chip |
| System Cooling | Fans: Up to 7 Removable heavy-duty 4cm Fan(s) Liquid Cooling: Direct to Chip (D2C) Cold Plate (optional) |
| Power Supply | 2x 2700W Redundant Titanium Level (96%) power supplies |
| Dimensions and Weight | Weight: Gross Weight: 49.21 lbs (22.32 kg) Net Weight: 33.64 lbs (15.26 kg) Available Color: Silver |
