8 Ton Electric And Diesel Powered Steel Spider Crane With 3 Year Warranty
8 Ton Electric And Diesel Powered Steel Spider Crane With 3 Year Warranty
Product Description:
The Spider Crawler Crane is a powerful and reliable lifting solution. This 8 ton crane is made from high quality steel . It also features a telescopic boom which provides a safe and secure lifting operation. With its superior design and construction, the Spider Crawler Crane is an ideal choice for a wide range of heavy lifting applications. The crane is also designed to be lightweight and easy to transport, making it suitable for both indoor and outdoor use.
The Spider Crawler Crane is a reliable and efficient tool for lifting large objects. Its telescopic boom makes it easy to maneuver into different areas, allowing for greater flexibility and more precise lifting. The crane is also designed to be resistant to corrosion and wear, making it ideal for long-term use in a wide variety of industries. Its 7.5 ton weight makes it easy to move around.
The Spider Crawler Crane is a perfect solution for all types of heavy lifting. Its telescopic boom and superior design make it the perfect choice for those who require a reliable and efficient lifting solution. Its lightweight design and easy to transport features make it suitable for both indoor and outdoor use. With its 3 ton, 5 ton and 8 ton capacity, the Spider Crawler Crane is a must-have for anyone looking for a reliable and efficient lifting solution.
Features:
- Product Name: Spider Crawler Crane
- Power Source: Electric and Diesel
- Color: Customized
- Boom: Telescopic
- Capacity: 8 ton
- Electric Spider Crane: Available
- Spider Crane Diesel: Available
- Warranty: 3 Year
Technical Parameters:
| Model | EW 8.0 | |
| Specification | 8.t | |
| Maximum Working Radius | 16m×1t | |
| Maximum Ground Lifting Height | 17.8m | |
| Maximum Under Ground Lifting Height | 20.5m | |
| Winch Device | Hook Speed | 10m/min (4 ropes) |
| Rope diameter | Φ11mm×100m | |
| Telescopic system | Boom Type |
5 section booms, hexagonal structure, two sections can be extended independently |
|
Length of telescopic boom
|
4.7m~16.5m | |
| Boom Length/Time | 12.3m/54sec | |
| Up and Downs | Boom Angle/Time | 0~75°/25sec |
| Slew System | Slew Angle/Time | 0-360° continuous/38sec |
| Outrigger | Outrigger Active Form | Manual spin out + oil pressure automatic support (two section outrigger) |
| Maximum Extended Dimensions | 7800×3600mm | |
|
Traction system |
Walking Way | Hydraulic motor drives |
| Walking Speed | 0-2.5km/h | |
| Traction device | Track synthetic rubber | |
| Grade Ability | 20° (36%) | |
| Engine | Manufacturer | YUNNEI |
| Type/discharge | 490 | |
| Starting Method | Electric starting | |
| Starting performance | -5°C~40°C | |
| Fuel/volume | Diesel/48L | |
| Battery capacity | 12V 45AH | |
| Operating system | Operation type (Boom/outrigger) | Manual operation, manual walking |
| Operating characteristics | Manual operation,remote control | |
| Dimension | Length x Width x Height | 5000×1600×2200(mm) |
| Weight | Vehicle Weight | 7500kg |
Applications:
The EW8.0 Spider Crane is a powerful and versatile product from EW, designed for heavy lifting up to 8 Ton. It features a telescopic boom for maximum reach and height, as well as a durable steel construction and customizable color. It has been CE certified, and with a minimum order quantity of 1, a wooden package and delivery time of 30 days, it's sure to meet all your requirements. With its competitive price and reliable performance, this spider crane is the perfect choice for any industry.
Packing and Shipping:
- The product is securely packaged in a box.
- The box is sealed with heavy-duty adhesive tape.
- The box is then placed inside an appropriate-sized shipping container.
- The shipping container is then sealed with a plastic shipping bag.
- The container is labeled with the appropriate shipping information.
- The package is then sent via the shipping carrier of the customer's choice.
