Car MCH Ceramic Heater Piece 20*18*9mm Alumina Ceramic Heaters
Car MCH Ceramic Heating Piece 20*18*9mm Alumina Ceramic Heating Heating Plate Power Optional
Description
The heating circ
uit is printed in the alumina ceramic, which is integrated through sintering, completely isolated from the external gas, and plays a role of protection and insulation.
Advantage
It has simple structure, rapid heating, fast temperature compensation, high power density, high heating temperature, which can reach more than 500 degrees Celsius, high thermal efficiency, energy saving, uniform heating, no open flame, safe use, long life, reduced power attenuation, heating circuit and air isolated. It is resistant to acid and alkali and meets environmental protection requirements. It is widely used in daily life, industrial agriculture, communication, medical treatment, and environmental protection. The current market ceramic heating elements include: sheet heating element, round rod heating element, disc heating element, round tube heating element, etc.
Main technical parameters
| Product Name |
Car MCH Ceramic Heating Piece 20*18*9mm Alumina Ceramic Heating Heating Plate Power Optional |
| Max. Temperature | used up to max. 600 ° C |
| Power | 12-100 |
| Warpage | ＜0.2mm |
| Leads Tensile Strength |
axial direction ≥ 5 acros direction ≥ 3 |
| Lead | 1mm industrial nickel wire(The length depends on the customer) |
| Application | Industrial drying equipment, electric Bonding liquid heater |
We are able to tailor heating elements according to your wishes. The electrical data, such as voltage, resistance and power, as well as the component dimensions can be customized within wide ranges. The heating surface can vary from a few mm² to about 100 cm².
From the high-quality standard product to the tailor-made heating element, we meet every customer request..
Application
· Home Appliance: small warm-air heater, air purifiers, houlsehold deodorization, clothes dryer, electric heating splint, iron, electric iron, thermos flask, insulation cabinet, electric cooker, smart toilet ceramic heater, instant heating water dispenser, etc.
· Beauty: hair dryer,hair straightener, curling iron, masssagers, humidifiers, facial steamer etc.
· Kitchen and Bathroom: coffee machine, yogurt maker, baby bottle warmer, sterilizer, beverage machine, instant heating water dispenser, electric faucets, showers, smart toilet ceramic heater etc.
· Medical Field: Infrared physiotherapy instrument, intravenous injection heater, forehead thermometer,ventilator, dialysis machine, nuclear acid extractor, moxi-bustion etc.
· Popular Field: HNB cigarettes, 3D printing etc.
