BP93420-IC 4-20mA Pressure Transmitter 0.5% Accuracy IP65

Price Negotiable

Price: 18

MOQ: 1

Delivery Time: Negotiable

Brand: HT

Product Description

BP93420-IC Pressure Transmitter

Product Overview

The BP93420-IC is a high-temperature pressure transmitter featuring an advanced HT series silicon pressure-resistance isolation oil-filled core. Its specialized heat dissipation structure efficiently captures medium pressure, making it ideal for demanding high-temperature environments and applications with temperature fluctuations.

Key Features

Wide measuring range with stainless steel construction
Multiple pressure interface options available
IP65 protection rating
Adjustable zero and full-scale settings
High precision measurement
All stainless steel structure for durability

Applications

Pressure measurement of non-corrosive gases and liquids (316L stainless steel compatible)
Marine and aviation industries
Industrial processes including petroleum, chemical, metallurgy, power generation, and hydrology
Hydraulic and pneumatic control systems

Technical Specifications

Measurement Range	-100kPa...0kPa ~ 10kPa...100MPa
Pressure Type	Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload Capacity	≤ 1.5 times of rated range
Accuracy @ 25ºC	±0.25% (Typical) ±0.5% (Maximum)
Repeatability	0.1%FS
Hysteresis	0.1%FS
Long-Term Stability	±0.1%F.S/Year(Typical) ±0.2%F.S/Year(Maximum)
Zero Point Temperature Drift	±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Full Scale Temperature Drift	±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Frequency Response	2.4Khz
Operating Temperature	-20ºC~150ºC
Storage Temperature	-40ºC~120ºC
Housing Material	304, 316L Stainless Steel
Protection Rating	IP65
Explosion-proof Rating	Ex db IIC T6 Gb
Weight	~0.3kg

Output Signal Options

BP93420-IC Pressure Transmitter front view

BP93420-IC Pressure Transmitter side view

Ordering Information

Important considerations when ordering:

Ensure medium compatibility with product contact parts
Explosion-proof models don't include digital display heads
Models with LCD/LED displays require ≥20VDC power supply
Recommended to install lightning protection and ensure proper grounding
Fluoro rubber O-ring rated for -20ºC to 250ºC (EPDM required below -20ºC)
Default cable: 1.5m polyethylene (other materials available on request)
Specify special requirements (vibration, EMI/RFI, etc.) when ordering

Order Guide

Order Guide
BP93420XX BPHT24	Pressure Transmitter
	Code	Outline Construction
	I	With Cable			IX	Display Pressure Transmitter
	IB	Hirschmann Pressure Transmitter			IIC/III	Industrial General/ Display Pressure Transmitter (2088)
	IE	Shock-resistant Aviation Pressure Transmitter			IC	High-temperature Pressure Transmitter
	IQ	50.4mm Clamp Pressure Transmitter			IQT	50.4mm Clamp High-temperature Pressure Transmitter
		Measurement Range	-0.1. . .0～0.01．．．100MPa
		(0-X)Kpa or MPa	X: Indicates the Actual Measuring Range
			Code	Power Supply
			D1	24VDC
			D2	5VDC
			D3	Other
				Code	Output Signal
				S1	4～20mADC	S5	0～20mADC
				S2	1～5VDC	S6	0～10VDC
				S3	0～5VDC	S7	0.5～4.5VDC
				S4	0～10mADC	S8	RS485
					Code	Pressure Connection
					J1	M20×1.5
					J2	G1/2
					J3	G1/4
					J4	1/2NPT
					J5	1/4NPT
					J6	G1/2, Flush Structure
					J7	50.4 clamp
					J8	50.4 clamp with Heat Sink
							Code	Pressure Type
							G	Gauge Pressure
							A	Absolute Pressure
							S	Sealed Reference Pressure
