BP93420DII Differential Pressure Transmitter 4-20mA Output for Industrial Applications Differential Pressure Sensor
Price:
60
MOQ:
1
Delivery Time:
Negotiable
Brand:
HT SENSOR
Product Description
BP93420DII Differential Pressure Transmitter 4-20mA Output for Industrial Applications Differential Pressure SensorBP93420DII Pressure Control System
G1/4 & 1/4NPT Differential Pressure Transducer & Transmitter
Product Overview
The BP93420DII differential pressure transmitter utilizes advanced piezoresistive diffused silicon sensor technology. When differential pressure acts on the corrugated diaphragms at both sensor ends, the Wheatstone bridge output signal maintains excellent linear correlation with the pressure differential, ensuring precise measurement accuracy.
Key Features
- Stainless steel construction for compact design and easy installation
- Rigorous temperature compensation and aging screening for stable, reliable performance
- Flexible electrical interface options: plug-in or direct wiring configurations
Industrial Applications
- Differential pressure measurement for gases and liquids in pipeline systems
- Industrial process monitoring in petroleum, chemical, metallurgy, power generation, and hydrology sectors
- Pressure measurement for pipelines and furnace chamber applications
Technical Specifications
| Measurement Range | 0-10KPa...~2MPa |
|---|---|
| Pressure Type | Differential Pressure |
| Single-side Overload | ≤3 times of rated range |
| Static Pressure | Minimum of 5 times rated range or 7 MPa |
| Accuracy @ 25ºC | ±0.25% (Typical) ±0.5% (Maximum) |
| Repeatability | ±0.03% (Typ.) ±0.05%FS (Max.) |
| Hysteresis | ±0.03% (Typ.) ±0.05%FS (Max.) |
| Long-Term Stability | ±0.5%F.S/Year(≤200KPa) ±0.2%F.S/Year(>200KPa) |
| Zero Temperature Drift | ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa) |
| Span Temperature Drift | ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa) |
| Compensation Temperature | 0-50ºC(0-10KPa, 0-20KPa), 0-70ºC, -10-70ºC |
| Operating Temperature | -30ºC~80ºC |
| Storage Temperature | -40ºC~100ºC |
| Vibration Resistance | 10g, 55Hz ~ 2kHz |
| Housing Material | 304, 316L Stainless Steel |
| Diaphragm Material | 316L Stainless Steel |
| Insulation Resistance | 100MΩ 100VDC |
| Explosion-proof Rating | Intrinsically safe and explosion-proof |
| Protection Rating | IP65 |
| Weight | ~0.45kg |
Output Signal Configuration
| Output Signal | Supply Voltage | Output Type |
|---|---|---|
| 4~20mA | 12~30VDC | 2/3/4 wire |
| 0~10/20mA | 3 wire | |
| 0/1~5V 0.5~4.5V |
5VDC |
Installation Guidelines
- Verify measured medium compatibility with product contacting materials before selection
- Install three-valve manifold between measurement point and transmitter for reliable operation
- Position pressure interfaces horizontally to minimize installation location impact
- Specify special requirements (vibration, impact, EMI/RFI) during ordering process
Ordering Information
| Component | Code | Description |
|---|---|---|
| Product Series | BP93420XX | Pressure Transmitter |
| Construction Type | DII | Differential Pressure Transmitter |
| Measurement Range | 0-10KPa...~2MPa | |
| Power Supply | D1 | 24VDC |
| Power Supply | D2 | 5VDC |
| Power Supply | D3 | Other |
| Output Signal | S1 | 4~20mADC |
| Output Signal | S2 | 1~5VDC |
| Output Signal | S3 | 0~5VDC |
| Output Signal | S4 | 0~10mADC |
| Output Signal | S5 | 0~20mADC |
| Output Signal | S6 | 0~10VDC |
| Output Signal | S7 | 0.5~4.5VDC |
| Pressure Connection | J1 | M20×1.5 Male |
| Pressure Connection | J2 | G1/2 Male |
| Pressure Connection | J3 | G1/4 Male |
| Pressure Connection | J4 | 1/2 NPT Male |
| Pressure Connection | J5 | Other |
| Electrical Connection | B1 | Hirschmann |
| Electrical Connection | B2 | PG7 Plug |
| Electrical Connection | B3 | Sealed Cable Output |
| Electrical Connection | B4 | Other |
| Pressure Type | D | Differential Pressure |
Frequently Asked Questions
- What are the key features of your pressure sensor transmitters?
- Our transmitters offer high precision, exceptional durability, and reliable performance. Customization options are available to meet specific application requirements.
- Can I request custom specifications?
- Yes, our engineering team can develop tailored solutions for unique applications. We provide comprehensive OEM and ODM services.
- What is your production capacity?
- Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters monthly, ensuring we can accommodate large-scale orders. Contact our sales team for production scheduling.
- What is the typical delivery timeframe?
- Standard models typically ship within 5-8 working days. Customized products may require additional time based on specifications.
- How are products priced? Are volume discounts available?
- We offer competitive pricing with attractive discounts for bulk orders and long-term partnership agreements.
- What warranty and after-sales support do you provide?
- All products include a 24-month warranty from shipment date. Our technical support team responds to inquiries within 24 hours, with remote PC network assistance available.
