BH93420-I Stainless Steel IP68 Waterproof 4-20mA Output Liquid Level Transmitter and Pressure Sensor Transmitter
Price:
40
MOQ:
1
Delivery Time:
Negotiable
Brand:
HT SENSOR
Product Description
BH93420-IT Special Medium Pressure Transmitter
High Temperature Corrosion Resistant Level Sensor with full stainless steel construction and IP68 protection rating.
Product Overview
The BH93420-I water level transmitter utilizes HT series diffused silicon isolation oil-filled core technology as its signal measuring element. Featuring a robust full stainless steel housing and compact one-piece structure, this immersion-type sensor delivers exceptional performance in demanding environments.
Key Features
- Full stainless steel housing for diverse testing environments
- Immersion-type probe measurement for easy installation
- Multiple output signal options for system compatibility
- Explosion-proof certification: ExiaIICT6
- High protection rating: IP68
- Available with PE or PU cable options
Applications
- Compatible with 316L stainless steel and non-corrosive liquids
- Water level monitoring in sewage, industrial, municipal systems, tanks, wells, rivers, seawater, and lakes
- Fuel level measurement in diesel and fuel storage tanks
Performance Specifications
| Measurement Range | 0~10m…400m |
|---|---|
| Overload Capacity | ≤ 2 X of rated range |
| Accuracy @ 25ºC | ±0.25% (Typ.) ±0.5% (Max.) |
| Repeatability | ±0.03% (Typ.) ±0.05%FS (Max.) |
| Long-Term Stability | ±0.2%F.S/year (Max.) |
| Operating Temperature | -20~80ºC |
| Housing Material | 1Cr18Ni9Ti |
| Diaphragm Material | 316L Stainless Steel |
| Explosion-proof Rating | ExiaIICT6 |
| Protection Rating | IP67, IP68 |
Output Signal Options
| Output Signal | Supply Voltage | Output Type |
|---|---|---|
| 4~20mA | 12~30VDC | 2/3/4 wire |
| 0~10/20mA | 12~30VDC | 3 wire |
| 0/1~5V, 0/1~10V, 0.5~4.5V | 5VDC | 2 wire |
| RS485 Communication Protocol | 3.6~30V / Battery | 4 wire |
Ordering Information
Ordering Tips
- Verify compatibility between measured medium and product components
- Specify the density of the measured medium
- For strong electromagnetic or RF interference environments, provide details during ordering
- Install lightning protection devices and ensure proper grounding for reliable operation
Order Guide
| Component | Code | Description |
|---|---|---|
| Base Model | BH93420 | Pressure Transmitter |
| Measurement Range | I | 0~10m…400m |
| Power Supply | D1 | 24VDC |
| Power Supply | D2 | 5VDC |
| Power Supply | D3 | Other |
| Output Signal | S1 | 4~20mADC |
| Output Signal | S5 | 0~20mADC |
| Cable Material | C1 | PE |
| Cable Material | C2 | PU |
Frequently Asked Questions
- What are the features of your pressure sensor transmitters?
- High precision, durability, and excellent performance. Customization available.
- Can I customize special specifications?
- Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service.
- What is your production capacity?
- Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling.
- What's the typical delivery period?
- 5~8 working days for standard models. Customized products may vary.
- How are the products priced? Any discounts?
- Competitive pricing with discounts for bulk orders or long-term partners.
- What is the warranty of your products? And after-sales service?
- Our warranty time is 24 months after shipment, and our after-sales will respond to your questions within 24 hours. Remote instruction by PC network is always available.
