Horizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer Plant

Price Negotiable

Price: USD11000-32500 set

MOQ: 1

Delivery Time: 15-25DAYS

Brand: TAIGUO

Product Description

Horizontal Chain Grate 50 Ton Coal-Fired Water Tube Steam Boiler for Fertilizer Plant

Model item		SZL6	SZL8	SZL10	SZL15	SZL20	SZL25	SZL30	SZL35
Rated evaporation capacity(t/h)		6	8	10	15	20	25	30	35
Rated pressure( Mpa)		1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5	1.25/1.6/2.5
Rated steam tmperature(℃)		194/204/226	194/204/226	194/204/226	194/204/226	194/204/226	194/204/226	194/204/226	194/204/226
Feed water temperature (℃)		20	20	20	20	20	20	20	20
Heating Area(㎡)	Body	~142	~215	~234	~318.5	~504	~646	~738	~852.3
Heating Area(㎡)	Economizer	130	130	174	348.8	377.6	500.6	551	685.8
Effective area of garte (㎡)		7.52	10.25	11.8	18	23.2	29.8	35	41.2
Fuel type		Coal, Biomass pellet, jute, Palm kernel shell
Fuel Consumption(kg/h)		~880	~1160	~1450	~2200	~2900	~3650	~4350	~5100
Exhaust flue gas temperature(℃)		~165	~165	~165	~165	~165	~165	~165	~165
Themal efficiency(%)		~80	~80	~80	~80	~80	~80	~80	~80
Weight of biggest part fotransportation (t)		22.5	25	28	30	35	40	45	50
Overlall dimension part for transportation LWH(mm)		up:615028403540 Down:727528522580	Up:697129333540 Down:805629452580	Up:785532403540 Down:902532002580	Up:1000032403540 Down:1200032003080	Up:1100032403540 Down:1400032003080	Up:1200032403540 Down:1600032003080	Up:1300032403540 down:1800032003080	Up:1400032403540 Down:2000032003080
